High Tier - Top Tier SPAA Mega List

RemoveCASfromGRB · July 25, 2024, 6:51am

Part 1

USA - Germany - Russia - UK - Japan - China

To Add or Not to Add - That is the Question

How often have you seen someone saying…

“There is no equivalent to the Pantsir”
“X nation doctrine didn’t focus on SHORAD.”

While some of those statement are partial truths. Its an indisputable fact that the Pantsir is the best SPAA and all other nations need new SPAAs.

So here is a SPAA Mega list
Some SPAA systems in this list of Patriot Style systems and Gaijin hasn’t crossed that bridge yet.

This list is to compile possible SPAAs and future SPAAs into a single thread. Its not about if it should be added, its to bring attention to a systems existence outside of digging through suggestions.

USA:
DIVAD - Chapfire - Libya

Spoiler

1. M1097 SL-AMRAAM

m02007062400083

Missiles:
AIM-120A-C (In-Game)
Range: 16 km

Spoiler

Caliber: 178mm
Mass: 147.87 kb
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH / IOG / DL
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

SL-AMRAAM ER (AIM-120B or Cs with booster motor)
Range: 40 km

Spoiler

Caliber: 178mm (Booster 254mm)
Mass: n/a
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

Ammo & Radar Info
Radar: Towed AN/MPQ-65 ETARC Radar - (75 km)
Ready Ammo - 6x Missiles
Stowed Ammo - n/a
Missile Config - 4x AIM120A-C or 4x SL-AMRAAM ER | 2x AIM-9XB2

2. M1085 SL-AMRAAM

Missiles:
AIM-120A-C (In-Game)
Range: 16 km

Spoiler

Caliber: 178mm
Mass: 147.87 kb
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH / IOG / DL
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

SL-AMRAAM ER (AIM-120B or Cs with booster motor)
Range: 40 km

Spoiler

Caliber: 178mm (Booster 254mm)
Mass: n/a
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

Ammo & Radar Info
Radar: Towed AN/MPQ-65 ETARC Radar - (75 km)
Ready Ammo - 6x or 4x Missile
Stowed Ammo - n/a
Missile Config - Single

3. LAVRAAM

LAVRAAM

Missiles:
AIM-120A-C (In-Game)
Range: 16 km

Spoiler

Caliber: 178 mm
Mass: 147.87 kb
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH / IOG / DL
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

SL-AMRAAM ER (AIM-120B or Cs with booster motor)
Range: 40 km

Spoiler

Caliber: 178mm (Booster 254mm)
Mass: n/a
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: ARH
Max Overload: 35 G
Guidance Time: 80s
TNT equivalent: 9.81 kg

Ammo & Radar Info
Radar: Unknown
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

4. M-SHORAD + Second Suggestion

Missiles:
AGM-114L
Range: 9.5km

Spoiler

Caliber: 180mm
Mass: 45.7 kg
Max Speed: Mack 1.3 (475 m/s) (In-Game 114K)
Guidance Type: MMW ARH
Max Overload: n/a
Guidance Time: 45s (In-Game 114K)
TNT equivalent: 9.43 kg (In-Game 114K)

FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

NGSRI (Stinger Replacement)

Guns:
XM914 30mm

Ammo & Radar Info
Radar: MHR S-Band Pulse Dopplar Radar - ?? km | (3D AESA - AN-RPS-42 MHR) - (20-35 km)
Ready Ammo - 4-8x Missiles
Stowed Ammo - n/a
Missile Config - 8x FIM-92, 4x FIM-92 | 2x AGM-114L

5. MSL + Additional Source #1

Missiles:
AGM-114L
Range: 9.5km

Spoiler

Caliber: 180mm
Mass: 45.7 kg
Max Speed: Mack 1.3 (475 m/s) (In-Game 114K)
Guidance Type: MMW ARH
Max Overload: n/a
Guidance Time: 45s (In-Game 114K)
TNT equivalent: 9.43 kg (In-Game 114K)

AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

Ammo & Radar Info
Radar: Search and Track Capable
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - 2x AIM-9X | 4x AGM-114L

6. FMTV MML (Multi-Mission Launcher) / IPFC Inc 2-I + Additional Source #1

Enduring Shield

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Missiles:
AGM-114L
Range: 9.5km

Spoiler

Caliber: 180mm
Mass: 45.7 kg
Max Speed: Mack 1.3 (475 m/s) (In-Game 114K)
Guidance Type: MMW ARH
Max Overload: n/a
Guidance Time: 45s (In-Game 114K)
TNT equivalent: 9.43 kg (In-Game 114K)

AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

Tamir Interceptor
Range: 10 - 15 km

Spoiler

Caliber: 160mm
Mass: 90 kg
Max Speed: Mack 2.2 (754.6 m/s)
Guidance Type: E/O (Unconfirmed)
Max Overload: n/a
Guidance Time: n/a
Warhead: 11 kg

Ammo & Radar Info
Radar: Towed Radar Trailer (AN/MPQ-64 Sentinel)
Ready Ammo - 15x
Stowed Ammo - n/a
Missile Config - Any missile configuration.

7. Enduring Shield + Additional Source #1 – Patriot Style System

Missiles:
AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

Ammo & Radar Info
Radar: n/a
Ready Ammo - 18x
Stowed Ammo - n/a
Missile Config - 18x Single

8. Liberty M-113 ll + Additional Source #1

Missiles:
VT-1 (In-Game)
Range: 11 km

Spoiler

Caliber: 165mm
Mass: 73 kg
Max Speed: Mack 3.6 (1,250 m/s)
Guidance Type: SACLOS
Max Overload: 50 g
Guidance Time: 20s
TNT equivalent: 7.86 kg

Ammo & Radar Info
Radar: Unknown Radar
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - 12x Single

9. MIM-46 Mauler

MIM-46_Mauler_c1963

Missiles:
XMIM-46A
Range: 8 km

Spoiler

Caliber: 127mm
Mass: 54.4 kg
Max Speed: Mack 2.9 (1,000 m/s)
Guidance Type: Beam-Riding
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 8.6 kg

Ammo & Radar Info
Radar: Beam-Riding guidance
Ready Ammo - 9 or 12x
Stowed Ammo - n/a
Missile Config - 9 or 12x Single

10. AN/TWQ-1 Avenger + Additional Source #1 + Additional Source #2

ANTWQ-1 Avenger

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

StarStreaks (In-Game)
Range: 7 km

Spoiler

Caliber: 130mm
Mass: 14 kg
Max Speed: Mack 3.4 (1,178 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: 12s
TNT equivalent: 1.57 kg

AIM-9C (In-Game) AIM-9 Possible, assuming 9C
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 95 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SARH
Max Overload: 18 G
Guidance Time: 60s
TNT equivalent: 4.69 kg

Guns:
.50Cal Browning

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single | 4x Split

11. HVSD/ADAMS

Missiles:
Barak-1
Range: 12 km

Spoiler

Caliber: 170mm
Mass: 98 kg
Max Speed: Mack 2.1 (720 m/s)
Guidance Type: Radar CLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 22 kg

Guns:
Mk.15 Phalanx Block 1B PSuM

Ammo & Radar Info
Radar: Digital MTI Search Radar, Ku Band (14-15Ghz) | Pulse Doppler Monopulse Track Ku Band - (20 km)
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - 12x Single

12. AMPV + Additional Source #1

Missiles:
AGM-114L
Range: 9.5km

Spoiler

Caliber: 180mm
Mass: 45.7 kg
Max Speed: Mack 1.3 (475 m/s) (In-Game 114K)
Guidance Type: MMW ARH
Max Overload: n/a
Guidance Time: 45s (In-Game 114K)
TNT equivalent: 9.43 kg (In-Game 114K)

FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
XM914 30mm

Ammo & Radar Info
Radar: Leonardo DRS’ Multi-Mission Hemispheric Radar
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single | 4x Split

13. M6 Bradley Linebacker + Additional Source #1

ve_micv_bradley_v3

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
25mm M242 Trashmaster
Range: ~~

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x
Stowed Ammo - 6x
Missile Config - 4x Single

14. M6A3 Bradley M-SHORAD

d111ae2543d6fed48726af74af439ea980ce2905

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
30mm XM914 Bushmaster
Range: ~~

Ammo & Radar Info
Radar: pMHR surveillance radar
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

15. Rapier Bradley

Missiles:
Rapier Mk.2
Range: 7-8 km

Spoiler

Caliber: 127mm
Mass: 43 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Guns:
25mm M242 Trashmaster

Ammo & Radar Info
Radar: Need Info
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

16. Bradley Trinity

Guns:
40mm L/70 Bofors

Spoiler

Rate of Fire: 330 rpm
Elevation: -5° to +85°
Ammo Types: HEFI-T / Trinity 3P / APDS

Ammo & Radar Info
Radar: Search Radar | Tracking Radar - (20 km)
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

17. M458 Eagle

Eagle 35mm Mobile Anti Air

Guns:
Ares Talon 35mm
Range: 4 km

Spoiler

Rate of Fire: 2x 600 rpm
Ready Rack: 2x 280 Drums
Ammo Types: APDS-T / HE-I / HEI-T / SAPHE-T
Feed System: Dual-Feed
Muzzle Velocity: 1,175 m/s

Ammo & Radar Info
Radar: Can be supported by 3rd party radar units
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

18. CAT-LCV + Additional Source #1

FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
75mm XM-274
Range: ~~

Spoiler

Ammo: 60 rounds
Rate of Fire: 60 or 70 rpm
Ammo Types: APFSDS / HE-VT

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

19. Vulcan Excalibur

Guns:
20mm M168
Range: ~~

Ammo & Radar Info
Radar: Inherits M163 Radar
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

20. Defender 2 HMMWV

Defender_II_HMMWV_mounted

Guns:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
25mm GE-225
Range: ~~

Ammo & Radar Info
Radar: Inherits Avenger Radar?
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

21. Mobile C-RAM Centurion

Guns:
20mm M61A1
Range: ~~

Spoiler

Rate of Fire: 3000 or 4500 rpm
Ammo Types: M246 / M940

Ammo & Radar Info
Radar: Ku Band pulse Doppler monopulse Radar | 8-12 micron wavelength | AN/TPQ-36 + FAAD C2
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

22. XM701 GLAADS

Guns:
25mm PFB-25
Range: ~~

Spoiler

Rate of Fire: 550 rpm

Ammo & Radar Info
Radar: IRST | 30scans/sec - (10 km)
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

23. XM44 FOG-M / EFOGM + Additional Source #1 (Page 154/155) + Additional Source #2 + Additional Source #3

FOG-M-Missile-892x859

Missiles:
MIM-157 FOG
Range: 10 km

Spoiler

Caliber: 150mm
Mass: 45 kg
Max Speed: 102 - 205 m/s
Guidance Type: Fiber Optic Guidance + IR Lock
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 1st Warhead I-TOW | 2nd Warhead TOW-2

YMGM-157B EFOGM
Range: 15 km

Spoiler

Caliber: 166mm
Mass: 53.3 kg
Max Speed: 100 m/s
Guidance Type: Fiber Optic Guidance + IR Lock
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Ammo & Radar Info
Radar: n/a
Ready Ammo - 6x or 8x
Stowed Ammo - n/a
Missile Config - Single

DIVAD Program Proposals

1. XM-246

89a0fcdfab9ffedc7bdb796b25947102dd4b97e6_2_750x507

Guns:
2x 35mm KDA

Spoiler

Ammo Capacity: 600
Ammo Types: HE-I / AP-I / APDS

Ammo & Radar Info
Radar: Unknown
Ready Ammo - 600 rounds
Stowed Ammo - n/a
Missile Config - n/a

2. T249 Vigilante + Additional Source #1 (Relevant to Sperry’s Proposal)

mokgritxgnq91

Guns:
37 mm T250

Spoiler

Rate of Fire: 3,000 rpm
Ammo Capacity: 192 rounds
Ammo Types: T324-E22 HE
Muzzle Velocity: 914 m/s

Ammo & Radar Info
Radar: Doppler-Pulse Search and Tracking
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

3. General Electric’s DIVAD Proposal

div_ge_0

Guns:
GAU-8 Avenger
Range: ~~

Spoiler

Rate of Fire: 4,200 rpm
Ammo Types: HE-I / AP-I (DU)
Muzzle Velocity: 1,000 m/s

Ammo & Radar Info
Radar: Doppler-Pulse Search and Tracking
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

4. Sperry’s DIVAD Proposals

div_sperry

Guns:
35 mm Modified T250
Range: ~~

Spoiler

Rate of Fire: Variable rpm 3,000 or 180 rpm
Ammo Capacity: 1,464 rounds
Ammo Types: Any 35mm KDA ammo

Ammo & Radar Info
Radar: Two Radars | IFF
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

Chapfire Varients -

1. MPLS Chapfire

a4436e3038c81a7c9f5ff4f19514199c2dda51cf

FziyI1PXoAEifET

Missiles:
MIM-72 (In-Game)
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 86.3 kg
Max Speed: Mack 2.09 (720 m/s)
Guidance Type: IR
Max Overload: 16.5 G
Guidance Time: 60s
TNT equivalent: 4.31 kg

AGM-114L ?
Range: 9.5 km

Spoiler

Caliber: 180mm
Mass: 45.7 kg
Max Speed: Mack 1.3 (475 m/s) (In-Game 114K)
Guidance Type: MMW ARH
Max Overload: n/a
Guidance Time: 45s (In-Game 114K)
TNT equivalent: 9.43 kg (In-Game 114K)

Hydra Rocket Pods
Range: ~~

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x or 6x
Stowed Ammo - n/a
Missile Config - Split

2. Bradley Chapfire

Bradley Chaparral.PNG

Missiles:
MIM-72 (In-Game)
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 86.3 kg
Max Speed: Mack 2.09 (720 m/s)
Guidance Type: IR
Max Overload: 16.5 G
Guidance Time: 60s
TNT equivalent: 4.31 kg

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

3. XM1108 Advanced Chaparral

Missiles:
MIM-72 (In-Game)
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 86.3 kg
Max Speed: Mack 2.09 (720 m/s)
Guidance Type: IR
Max Overload: 16.5 G
Guidance Time: 60s
TNT equivalent: 4.31 kg

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - Single

Libya (US Suggestion)

1. Captured Pantsir S1E

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

Guns:
2x 2A38M 30mm

Ammo & Radar Info
Radar: 2RL80 S-Band - (30 km) | 1RS2-1E Ku-Band Radar - (21 km)
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - 12x Single

Germany:
East Germany

Spoiler

1. IRIS-T SL-M

IRIS-T

Missiles
IRIS-T AAM
Range: 25 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mack 3 (1,029 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

IRIS-T SLS
Range: 12 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mack 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

IRIS-T SLM
Range: 40 km

Spoiler

Caliber: 177.8mm
Mass: 140 kg
Max Speed: Mack 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

Ammo & Radar Info
Radar: TRML-4D by HENSOLDT AESA Radar - (?? km) | SLM needs Radar Trailer
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single

2. ACSV G5 NASAMS

Missiles:
AIM-9X Block 2
Range: 15-16 km

Spoiler

Caliber: 127mm
Mass: 84.37 kg
Max Speed: Mach 2.5+ (857.5 m/s)
Guidance Type: IR
Max Overload: Estimated 60 G
Guidance Time: n/a
Warhead: 9.36 kg

IRIS-T AAM
Range: 25 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mack 3 (1,029 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

Ammo & Radar Info
Radar: XENTA-M Radar - 75 km
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - 4x Single | 2x Split

3. Boxer IRIS-T (Needs Maturity)

Boxer-IRIS-T-AD-German_GTK_Boxer_w-multiple_short-range_Rheinmetal-696x459

Missiles
IRIS-T AAM
Range: 25 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mack 3 (1,029 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

IRIS-T SLS
Range: 12 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mack 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

IRIS-T SLM
Range: 40 km

Spoiler

Caliber: 177.8mm
Mass: 140 kg
Max Speed: Mack 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

Ammo & Radar Info
Radar: n/a
Ready Ammo - 4x
Stowed Ammo - 4x
Missile Config - 4x Single

4. IRIS-T SLS Mk.3 + Additional Source #1

DIEHL_Defence_from_Germany_presents_its_new_IRIS-T_SLS_Mk_III_mobile_air_defense_system_925_001

Missiles
IRIS-T SLS
Range: 12 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

Ammo & Radar Info
Radar: Saab Giraffe 1X or Hensoldt Spexer X-band radar.
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

5. Skyranger 35 + Additional Link

Guns:
35mm
Range: 4 km

Ammo & Radar Info
Radar: Integrated Senor suite with X or Ku Band Radar (~30 km)
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

6. Skyranger 30

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Mistral 3
Range: 8 km

Spoiler

Caliber: 90mm
Launch Mass: 19.7 kg
Max Speed: Mach 2.71 (930 m/s)
Guidance Type: All-aspect IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.95 kg

KP-SAM Chiron
Range: 7 km

Spoiler

Caliber: 80mm
Launch Mass: 15 kg
Max Speed: Mach 2.5 (851 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.5 kg

Guns:
30mm
Range: 3 km

Ammo & Radar Info
Radar: AESA search radar, S or X bands - (20 km)
Ready Ammo - 2x
Stowed Ammo - n/a
Missile Config - 2x Single

7. Skyguard-M + Additional Source #1 + Additional Source #2

Missiles:
Roland 1 (In-Game)
Range: 6.3 km

Spoiler

Caliber: 163mm
Mass: 65 kg
Max Speed: Mack 1.46 (500 m/s)
Guidance Type: SACLOS
Max Overload: 15 G
Guidance Time: 13.8s
TNT equivalent: 4.59 kg

Roland 2 (In-Game)
Range: 6.3 km

Spoiler

Caliber: 163mm
Mass: 65 kg
Max Speed: Mack 1.46 (500 m/s)
Guidance Type: SACLOS
Max Overload: 15 G
Guidance Time: 13.8s
TNT equivalent: 4.59 kg

Roland 3 (In-Game)
Range: 8 km

Spoiler

Caliber: 163mm
Mass: 77 kg
Max Speed: Mack 1.66 (570 m/s)
Guidance Type: SACLOS
Max Overload: 20 G
Guidance Time: 17s
TNT equivalent: 6.81 kg

VT-1 (In-Game)
Range: 11 km

Spoiler

Caliber: 165mm
Mass: 73 kg
Max Speed: Mack 3.6 (1,250 m/s)
Guidance Type: SACLOS
Max Overload: 50 g
Guidance Time: 20s
TNT equivalent: 7.86 kg

MIM-72 (In-Game)
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 86.3 kg
Max Speed: Mack 2.09 (720 m/s)
Guidance Type: IR
Max Overload: 16.5 G
Guidance Time: 60s
TNT equivalent: 4.31 kg

AIM-9C (In-Game)
Range: 6 km

Spoiler

Caliber: 127mm
Mass: 95 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SARH
Max Overload: 18 G
Guidance Time: 60s
TNT equivalent: 4.69 kg

Rapier Mk.2
Range: 7-8 km

Spoiler

Caliber: 127mm
Mass: 43 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

HFK/KV
Range: 16-50 km

Spoiler

Caliber: 165mm
Launch Mass: 140 kg
Max Speed: Mach 5 (1,715 m/s) (Tested to Mach 7+ (2401 m/s))
Guidance Type: SACLOS - IR Seeker to guide KKV
Max Overload: 100 G
Guidance Time: n/a
TNT equivalent: 16 kg KKV

HFK/L2
Range: 16 km

Spoiler

Caliber: 165mm
Launch Mass: 100 kg
Max Speed: Mach 7 (2,401 m/s)
Guidance Type: n/a
Max Overload: 50 G
Guidance Time: n/a
TNT equivalent: n/a

AIM-7 AAM (Unknown Varient)
Range: ~~

Guns:
20mm Vulcan
Range: ~~

Ammo & Radar Info
Radar: Pulse-Doppler search and tracking radars | Electro-Optical target track
Search Radar on IEEE S or X (NATO E-F or I-Lower J Band)
Track Radar on IEEE Ku or X (NATO I-J Band)
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - 6x Any Config

8. Fennek SWP + Forum Suggestion

FennekSWP

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Ammo & Radar Info
Radar: n/a
Ready Ammo - 4x
Stowed Ammo - 4x
Missile Config - 4x Single

9. FlaRakRad 8x8 Evolution

Allow current FlaRakRad to have a mod that adds 2 more missile tubes or add this a new vehicle

10. ZSU Matador + Additional Source #1

D5Oa_FLUUAEFkOY

Guns:
2x 30mm

Spoiler

Ammo: 400 Rounds
Rate of Fire: 700-800 rpm

Ammo & Radar Info
Radar: MPDR-12 Target Detection | Inherits Goepard Tracker?
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

11. RU 222 | Flakpanzer 30mm Zwilling auf Truppenversuchsmuster

Nimxfhrfyjryjykjdtkyeta.png.07e84fa3c7d02611c268064ebe5bb089

Guns:
2x 30mm

Spoiler

Ammo: 400 Rounds
Rate of Fire: 700-800 rpm

Ammo & Radar Info
Radar: n/a
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

12. Sky Warden NNbS + Additional Source #1 + Additional Source #2

Missiles
Enforcer SADM
Range: 2 km

Spoiler

Caliber: 90mm
Mass: 15 kg
Max Speed: n/a
Guidance Type: IR | TV + Thermal | E/O
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Mistral 3 (Planned)
Range: 8 km

Spoiler

Caliber: 90mm
Launch Mass: 19.7 kg
Max Speed: Mach 2.71 (930 m/s)
Guidance Type: All-aspect IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.95 kg

Ammo & Radar Info
Radar: Passive & Active Sensors - Need more Info
Ready Ammo - 18x
Stowed Ammo - n/a
Missile Config - Single

13. LFK NG LeFla auf OZELOT - Dual-Purpose Missile

Missiles:
LFK NG
Range: 10 km

Spoiler

Caliber: 110mm
Launch Mass: 19 kg
Max Speed: Mach 2.5 (857.5 m/s)
Guidance Type: IR | DL + IOG
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 2.5 kg
Penetration: 560mm

Ammo & Radar Info
Radar: Inherits OZELOT Radar
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

14. Dornier LLADS

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

East German -

1. 9K33-M3 Osa + Suggestion #2

GermanOSA

Missiles:
9M33M3
Range: 15 km

Spoiler

Caliber: 209.6mm
Launch Mass: 170 kg
Max Speed: Mach 2.97 (1,020 m/s)
Guidance Type: RF CLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 15 kg

Ammo & Radar Info
Radar: 1S51M3-2 Radar | H Band (6 to 8 Ghz) - (30 km)
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - 6x Single

2. UAZ-469 FASTA-4M

be2c1ff983852f1b37ecf4b1355eb81de1b5e87e_2_500x331

Missiles:
9K32M (Strela-2M)
Range: 4.2 km

Spoiler

Caliber: 72mm
Launch Mass: 9.8 kg
Max Speed: Mach 1.45 (500 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 1.15 kg

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

Russia:
Belarus

Spoiler

1. Pantsir-S1M

Pantsir-S1M_sep2021_Rosoboronexport

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

57E6M-E
Range: 30 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5+ kg
Max Speed: Mack 4.95 (1,700 m/s)
Guidance Type: SACLOS
Max Overload: 32+ G
Guidance Time: n/a
Warhead: 25 kg

Guns:
2x 2A38M
Range: 2 km

Ammo & Radar Info
Radar: SOTS Search Radar - (80 km) | More info on Tracking needed - See Source
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

2. Pantsir-SA

Pantsir-SA_Arctic_short-range_air_defense_missile_system_Russia_Russian_army_military_equipment_640_004

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

Ammo & Radar Info
Radar: Autonomous acquisition and tracking radar 1RS2-1
Ready Ammo - 18x
Stowed Ammo - n/a
Missile Config - Single

4. Pantsir-SM-SV + Additional Source #1

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

57E6M-E
Range: 30 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5+ kg
Max Speed: Mack 4.95 (1,700 m/s)
Guidance Type: SACLOS
Max Overload: 32+ G
Guidance Time: n/a
Warhead: 25 kg

Guns:
2x 2A38M
Range: 2 km

Ammo & Radar Info
Radar: Multi-Functional Targeting Radar - (75 km)
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

4. Pantsir-SM

unnamed

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

57E6M-E
Range: 30 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5+ kg
Max Speed: Mack 4.95 (1,700 m/s)
Guidance Type: SACLOS
Max Overload: 32+ G
Guidance Time: n/a
Warhead: 25 kg

19Ya6
Range: 7 km

Spoiler

Caliber: n/a
Mass: n/a
Max Speed: Mach n/a
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
2x 2A38M
Range: 2 km

Ammo & Radar Info
Radar: Multi-Functional Targeting Radar | Jamming Resistant- (75 km)
Ready Ammo - 12x | 4-48x 19Ya6
Stowed Ammo - n/a
Missile Config - Single

5. Pantsir-SM-TBM + Additional Source #1

pantsir-s_1656577327

Missiles:
57E6-E (95YA6 Export)
Range: 18 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5 kg
Max Speed: Mack 3.8 (1,300 m/s)
Guidance Type: SACLOS
Max Overload: 32 G
Guidance Time: 30s
Warhead: 20 kg

57E6M-E
Range: 30 km

Spoiler

Caliber: 90mm (Booster 170mm)
Mass: 72.5+ kg
Max Speed: Mack 4.95 (1,700 m/s)
Guidance Type: SACLOS
Max Overload: 32+ G
Guidance Time: n/a
Warhead: 25 kg

19Ya6
Range: 7 km

Spoiler

Caliber: n/a
Mass: n/a
Max Speed: Mach n/a
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: Multi-Functional Targeting Radar? (75 km)
Ready Ammo - 24x | 4-96x 19Ya6
Stowed Ammo - n/a
Missile Config - Single

4. TOR-M2DT + Additional Source #1 + Additional Source #2 + Additional Source #3

TOR-M2DT

Missiles:
9M331 (In-Game)
Range: 12 km

Spoiler

Caliber: 239mm
Launch Mass: 167 kg
Max Speed: Mach 2.49 (850 m/s)
Guidance Type: SACLOS
Max Overload: 42 G
Guidance Time: 21s
TNT equivalent: 8.16

9M338
Range: 15 km

Spoiler

Caliber: 200mm (Unconfirmed)
Launch Mass: n/a
Max Speed: Mach 3 (1,029 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: 360° search radar 15 km 60° tracking radar | Infrared tracker - (25 km Search | 15 km Track)
Ready Ammo - 8x 9M331 | 16x 9M338
Stowed Ammo - n/a
Missile Config - 8x or 16x Single

5. 9M337 Sosna-R + Additional Source #1 + additional Source #2

sosna-1

Missiles:
9M340
Range: 10 km

Spoiler

Caliber: 72 mm (Booster 132mm)
Launch Mass: 42 kg
Max Speed: Mach 2.6 (891.8 m/s)
Guidance Type: Beam-Riding
Max Overload: n/a
Guidance Time: n/a
Warhead: 6.9 kg (Unconfirmed)

Guns:
2x 2A38M

Ammo & Radar Info
Radar: Multi-Channel Day/Night Electro-Optical Control | Laser & Radio Guidance
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - 12x Single

6. 9K33-M3 Osa

Missiles:
9M33M3
Range: 15 km

Spoiler

Caliber: 209.6mm
Launch Mass: 170 kg
Max Speed: Mach 2.97 (1,020 m/s)
Guidance Type: RF CLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 15 kg

Ammo & Radar Info
Radar: 1S51M3-2 Radar | H Band (6 to 8 Ghz) - (30 km)
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - 6x Single

7. Object 1040 “Ellipse” (OSA Prototype)

1524842938_obekt-1040-5

Missiles
9M33M3
Range: 15 km

Spoiler

Caliber: 209.6mm
Launch Mass: 170 kg
Max Speed: Mach 2.97 (1,020 m/s)
Guidance Type: RF CLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 15 kg

Ammo & Radar Info
Radar: Unknown if same OSA Radar
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - 4x Single

8. 9K37 Buk + Additional Source #1 + Additional Source #2 - Patriot Style System

Missiles
9M38
Range: 25-30 km

Spoiler

Caliber: 400mm
Launch Mass: 690 kg
Max Speed: Mach 2.48 (850 m/s)
Guidance Type: SARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 70 kg

Ammo & Radar Info
Radar: 9S18M1 Target Acquistion Radar - (85 km) Needs radar for guidance.
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - 4x Single

9. S-300V + Additional Source #1 + Additional Source #2 + Additional Source #3

9P82+9P83-TELARs-MiroslavGyurosi-1S

Missiles
9M82
Range: 100 km

Spoiler

Caliber: 1460mm
Launch Mass: 5,800 kg
Max Speed: Mach 5.24 (1,800 m/s)
Guidance Type: n/a
Max Overload: 20 G
Guidance Time: n/a
Warhead: 150 kg

9M83
Range: 75 km

Spoiler

Caliber: 915mm
Launch Mass: 3,600 kg
Max Speed: Mach 3.49(1,200 m/s)
Guidance Type: n/a
Max Overload: 20 G
Guidance Time: n/a
Warhead: 150 kg

Ammo & Radar Info
Radar: Dedicated ABM radar: the 9S19 HIGH SCREEN phased-array radar at battalion level
Ready Ammo - 4x 9M83 | 2x 9M82
Stowed Ammo - n/a
Missile Config - Single

10. Rapira-3 + Additional Source #1 + Additional Source #2

Missiles:
S-8OFP Rockets
Range: 2 - 4 km

Spoiler

Caliber: 80mm
Mass: 17 kg
Max Speed: Mack 1.58 (545 m/s)
Guidance Type: Laser Guided?
Max Overload: n/a
Guidance Time: n/a
Warhead: 9.5 kg

Ammo & Radar Info
Radar: Active phased array - (20 km)
Ready Ammo - 10x
Stowed Ammo - n/a
Missile Config - Single

11. Gibka-S + Additional Source #1

an48uqe035581

Missiles:
9K333 Verba
Range: 6.5 km

Spoiler

Caliber: 72 mm
Launch Mass: 17.25 kg
Max Speed: Mach 1.5 (515 m/s)
Guidance Type: Optical Seeker - N/M IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 1.5 kg

9M342 Igla-S
Range: 6 km

Spoiler

Caliber: 72 mm
Launch Mass: 11.7 kg
Max Speed: Mach 1.66 (570 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.5 kg

Ammo & Radar Info
Radar: Garmon 1L122-2E - (10 km)
Ready Ammo - 4x
Stowed Ammo - 4x
Missile Config - 4x Single

12. ZAK-23E

F3gJXTbXsAAaJiQ

Guns:
23mm 2A7M
Range: 2.5 km

Spoiler

Rate of Fire: 3500 rpm

Ammo & Radar Info
Radar: Unknown
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

14. 2S38 Derivatsiya (3OU7)

6235ca9d25b3c56d5e9ea9aa24736e33b40d0040_2_1000x562

Gun (Ammo):
57mm 2A90 3OU7 Guided Proximity

Add 3OU7 as new round or add higher tier 2S38 with 3OU7.

Belarus -

1. T38 Stilet + Additional Source #1 + Additional Source #2 + Additional Source #3 + Additional Source #4

4-image-33

Missiles:
9M33M3
Range: 15 km

Spoiler

Caliber: 209.6mm
Launch Mass: 170 kg
Max Speed: Mach 2.97 (1,020 m/s)
Guidance Type: RF CLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: 15 kg

T382
Range: 10 or 20 km

Spoiler

Caliber: 108mm (Booster 209mm)
Launch Mass: 116 kg
Max Speed: Mach 2.6 (900 m/s)
Guidance Type: RF CLOS
Max Overload: 25 G (Unconfirmed)
Guidance Time: n/a
Warhead: 18 kg

Ammo & Radar Info
Radar: E/O Tracking - (40 km Search)
Ready Ammo - 6x 9M33M3 | 8x T382
Stowed Ammo - n/a
Missile Config - 6x and 8x Single | 4x and 3x Split

UK:
Canada - India - South Africa

Spoiler

1. EMADS - Sky Sabre/Land Ceptor + Additional Source #1 + Additional Source #2 + Additional Source #3

Missiles:
CAMM
Range: 25 km

Spoiler

Caliber: 166mm
Launch Mass: 99 kg
Max Speed: Mach 3+ (1,029 m/s)
Guidance Type: ARH
Max Overload: 50 G
Guidance Time: n/a
Warhead: 10 kg

CAMM-ER
Range: 45 km

Spoiler

Caliber: 190mm
Launch Mass: 166 kg
Max Speed: Mach 3+ (1,029 m/s)
Guidance Type: ARH
Max Overload: 50 G
Guidance Time: n/a
Warhead: 10 kg

Ammo & Radar Info
Radar: E/O Targeting w/o Radar Vehicle - (100 km IRST? RESEARCH)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single

2. FLAADS-L (Prototype Sky Sabre) + Additional Source #1 + Additional Source #2 + Additional Source 3

Missiles:
CAMM
Range: 25 km

Spoiler

Caliber: 166mm
Launch Mass: 99 kg
Max Speed: Mach 3+ (1,029 m/s)
Guidance Type: ARH
Max Overload: 50 G
Guidance Time: n/a
Warhead: 10 kg

Ammo & Radar Info
Radar: Unknown Radar Specifications (See Sky Sabre for production specifications)
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

3. Tracked Rapier

Missiles:
Rapier Mk.2
Range: 7-8 km

Spoiler

Caliber: 127mm
Mass: 43 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Ammo & Radar Info
Radar: Pulse-Dopplar Search with IFF - (15 km)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single

4. Alvis Stormer Rapier Laserfire (Need more Information)

258550-cb6d7ecfd414fc0fcf997be19ccff71f

Missiles:
Rapier Mk.2
Range: 7-8 km

Spoiler

Caliber: 127mm
Mass: 43 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Ammo & Radar Info
Radar: LIDAR System
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - 4x Single

5. Stormer AD (Blazer-25/30)

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

Guns:
25mm or 30mm

Ammo & Radar Info
Radar: n/a
Ready Ammo - 2x
Stowed Ammo - n/a
Missile Config - 2x Single

6. Stormer Starburst

Missiles:
Starburst
Range: 7 km

Spoiler

Caliber: 76mm
Launch Mass: 166 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.74 kg (0.6 kg of HE)

Ammo & Radar Info
Radar: Inherits Stormer HVM
Ready Ammo - 8x
Stowed Ammo - 12x
Missile Config - 8x Single

7. Stormer Thunderbolt

thunderbolt

Missiles:
BAe CFAM Thunderbolt
Range: n/a

Spoiler

Caliber: 60mm (Booster?)
Launch Mass: n/a
Max Speed: Mach 4 (1,372 m/s)
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: Need Info
Ready Ammo - 8x or 12x Single
Stowed Ammo - n/a
Missile Config - Single

8. VERDI-2 Warror (Old Forum)

Missiles:
StarStreaks (In-Game)
Range: 7 km

Spoiler

Caliber: 130mm
Mass: 14 kg
Max Speed: Mack 3.4 (1,178 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: 12s
TNT equivalent: 1.57 kg

Guns:
40mm CTA

Ammo & Radar Info
Radar: Inherits Stormer HVM
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single

9. RapidRanger + Additional Source #1

RAPIDRanger

Missiles:
StarStreaks (In-Game)
Range: 7 km

Spoiler

Caliber: 130mm
Mass: 14 kg
Max Speed: Mack 3.4 (1,178 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: 12s
TNT equivalent: 1.57 kg

LMM
Range: 8 km

Spoiler

Caliber: 76mm
Mass: 13 kg
Max Speed: Mack 1.5+ (510 m/s)
Guidance Type: SALH/LOSBR
Max Overload: 30 G
Guidance Time: n/a
Warhead: 3 kg

Ammo & Radar Info
Radar: Passive Infra Red Search and Track (IRST) or integrated Surveillance and Track Radar - (15 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - 4x Single

10. Thor MMS

Missiles:
StarStreaks (In-Game)
Range: 7 km

Spoiler

Caliber: 130mm
Mass: 14 kg
Max Speed: Mack 3.4 (1,178 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: 12s
TNT equivalent: 1.57 kg

LMM
Range: 8 km

Spoiler

Caliber: 76mm
Mass: 13 kg
Max Speed: Mack 1.5+ (510 m/s)
Guidance Type: SALH/LOSBR
Max Overload: 30 G
Guidance Time: n/a
Warhead: 3 kg

AGM-114L (Need More Info)

Spike LR (Need More Info)

ZT3 Ingwe (Need More Info)

Ammo & Radar Info
Radar: Need More Info
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

11. Shorland S53 (Old Forum)

590614512_S5301.jpg.bd0f32b3fa96ae5629923e6a2e77e34c

Missiles:
Blowpipe
Range: 3.5 km

Spoiler

Caliber: 76mm
Launch Mass: 14.5 kg
Max Speed: Mach 1.5 (514.5 m/s)
Guidance Type: MCLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.2 kg

Javelin
Range: 5.5 km

Spoiler

Caliber: 76mm
Launch Mass: 12.7 kg
Max Speed: Mach 1.7+ (583.1 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.74 kg (0.6 kg of HE)

Starburst
Range: 7 km

Spoiler

Caliber: 76mm
Launch Mass: 166 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.74 kg (0.6 kg of HE)

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 3x
Stowed Ammo - 6x
Missile Config - 3x Single

12. MSI-DS Terrahawk Paladin + Additional Source #1 - D.R.O.P.S.

Guns:
Mk.44 Bushmaster 2 30mm
Range: 3 km

Spoiler

Ammo Type: HE-VT
Rate of Fire: Variable RoF 100 or 200 rpm

Ammo & Radar Info
Radar: Electro Optic Sensor | All-Weather Radar | 4x AESA Antennas
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

13. Rapier Bradley

Missiles:
Rapier Mk.2
Range: 7-8 km

Spoiler

Caliber: 127mm
Mass: 43 kg
Max Speed: Mack 2.5 (857.5 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
TNT equivalent: n/a

Guns:
25mm M242 Trashmaster
Range: ~~

Ammo & Radar Info
Radar: Need Info
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - 8x Single

14. Piranha Blazer

Missiles:
Blowpipe
Range: 3.5 km

Spoiler

Caliber: 76mm
Launch Mass: 14.5 kg
Max Speed: Mach 1.5 (514.5 m/s)
Guidance Type: MCLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.2 kg

Javelin
Range: 5.5 km

Spoiler

Caliber: 76mm
Launch Mass: 12.7 kg
Max Speed: Mach 1.7+ (583.1 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.74 kg (0.6 kg of HE)

Starburst
Range: 7 km

Spoiler

Caliber: 76mm
Launch Mass: 166 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: n/a
Warhead: 2.74 kg (0.6 kg of HE)

Guns:
25mm GAU-12
Range: ~~

Ammo & Radar Info
Radar: ESU Radar
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - Single

15. FMC M2 Bradley ICV

bradleyblazer

Missiles:
FIM-92 Stingers (In-Game 92K)
Range: 6 km

Spoiler

Caliber: 70mm
Mass: 10.1 kg
Max Speed: Mach 1.95 (670 m/s)
Guidance Type: IR
Max Overload: 13 G (Should be 20)
Guidance Time: 15s
TNT equivalent: 540 g

RBS 70 Mk.1 (In-Game)
Range: 5 km

Spoiler

Caliber: 105mm
Launch Mass: 16.5 kg
Max Speed: Mach 1.53 (525 m/s)
Guidance Type: Beam-Riding
Max Overload: 15 G
Guidance Time: 15s
Explosive Mass: 1.44 kg

RBS 70 Mk.2 (In-Game)
Range: 7 km

Spoiler

Caliber: 105mm
Launch Mass: 16.5 kg
Max Speed: Mach 1.69 (580 m/s)
Guidance Type: Beam-Riding
Max Overload: 17 G
Guidance Time: 24s
Explosive Mass: 1.44 kg

Guns:
25mm GAU-12
Range: ~~

Ammo & Radar Info
Radar: Ericsson Radar
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - Single

Canada -

1. MMEV (Multi-Mission-Effect Vehicle)

MMEV

Missiles:
MIM-146 (In-Game)
Range: 10 km

Spoiler

Caliber: 152mm
Launch Mass: 51 kg
Max Speed: Mach 2.99 (1,072 m/s)
Guidance Type: Beam-riding
Max Overload: 35 G
Guidance Time: 22s
Explosive Mass: 7.86 kg

IRIS-T SLS
Range: 12 km

Spoiler

Caliber: 127mm
Mass: 87.4 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: IR
Max Overload: 60 G
Guidance Time: n/a
TNT equivalent: 11.4 kg

CRV7-PG
Range: 12 km

Spoiler

Caliber: 70mm
Launch Mass: 51 kg
Max Speed: Mach 3.3 (1,132 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: n/a
Warhead: 4.5 kg

Ammo & Radar Info
Radar: Inherits ADATS Radar - (25 km)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Any Config

India -

1. Akash + Additional Source #1 – Patriot Style System

Akash

Missiles:
Akash
Range: 25-30 km

Spoiler

Caliber: 304.8 - 355.6mm
Launch Mass: 720 kg
Max Speed: Mach 1.8 - 2.5 (617 - 857.5 m/s)
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 60 kg

Ammo & Radar Info
Radar: Needs Radar Trailer
Ready Ammo - 3 or 4x
Stowed Ammo - n/a
Missile Config - Single

2. QRSAM 8x8 Vehicle + Additional Source #1 + Additional Source #2 + Additional Source #3

drdo-qrsam-quick-reaction-surface-to-air-missile-v0-6nwlww4lyz8c1

Missiles:
QRSAM
Range: 30 km

Spoiler

Caliber: 220mm
Launch Mass: 270 kg
Max Speed: Mach 4.7 (1612.1 m/s)
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 32 kg

Ammo & Radar Info
Radar: E/O Tracking
Ready Ammo - 4 or 6x
Stowed Ammo - n/a
Missile Config - Single

3. SAMAR + Additional Source #1 + Additional Source #2 + Additional Source #3

6eb077f410f4540c8fae623b08a9b49ffd682e19

Missiles:
R-73E (In-Game R-73, different Warhead for E)
Range: 12 km

Spoiler

Caliber: 165mm
Launch Mass: 105 kg
Max Speed: Mach 2.5 (857.5 m/s)
Guidance Type: IR
Max Overload: 40 G
Guidance Time: 25s
Warhead: 8 kg

R-27ET1 (In-Game R-27ET, different Warhead for ET1)
Range: 20 km (Rumored SL Range)

Spoiler

Caliber: 230mm
Launch Mass: 343 kg
Max Speed: Mach 4.5 (1,543.5 m/s)
Guidance Type: IR
Max Overload: 35 G
Guidance Time: 60s
Warhead: 39 kg

Ammo & Radar Info
Radar: n/a
Ready Ammo - 2x
Stowed Ammo - n/a
Missile Config - Single

4. SAMAR-ll

Missiles:
R-73E (In-Game R-73, different Warhead for E)
Range: 12 km

Spoiler

Caliber: 165mm
Launch Mass: 105 kg
Max Speed: Mach 2.5 (857.5 m/s)
Guidance Type: IR
Max Overload: 40 G
Guidance Time: 25s
Warhead: 8 kg

R-27ET1 (In-Game R-27ET, different Warhead for ET1)
Range: 20 km (Rumored SL Range)

Spoiler

Caliber: 230mm
Launch Mass: 343 kg
Max Speed: Mach 4.5 (1,543.5 m/s)
Guidance Type: IR
Max Overload: 35 G
Guidance Time: 60s
Warhead: 39 kg

Ammo & Radar Info
Radar: n/a
Ready Ammo - 2x
Stowed Ammo - n/a
Missile Config - Single

5. Armado BDL

FljbrgyaYAECzgT

Missiles:
StarStreaks (In-Game)
Range: 7 km

Spoiler

Caliber: 130mm
Mass: 14 kg
Max Speed: Mack 3.4 (1,178 m/s)
Guidance Type: Beam-riding
Max Overload: n/a
Guidance Time: 12s
TNT equivalent: 1.57 kg

Ammo & Radar Info
Radar: Strarstreak LML Targeting
Ready Ammo - 2x
Stowed Ammo - n/a
Missile Config - Single

6. Trishul SAM + Additional Source #1

YKzeN24ircJ4hoF2wEslfc-ozjXUudDlxj_pFwUM6VM

Missiles:
Trishul
Range: 9 km

Spoiler

Caliber: 200mm
Launch Mass: 130 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: CLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 15 kg

Ammo & Radar Info
Radar: Unspecified Radar
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

South Africa -

1. Umkhonto GBL + Additional Source #1 + Additional Source #2 – Unknown Patriot Style System

UMKHONTO_GBL

Missiles:
Umkhonto-IR Mk.2
Range: 15-20 km

Spoiler

Caliber: 180mm
Launch Mass: 130 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: All-aspect IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 23 kg

Umkhonto-R
Range: 60 km

Spoiler

Caliber: 180mm
Launch Mass: 130 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 23 kg

Umkhonto-ER-IR
Range: 35 km

Spoiler

Caliber: 180mm
Launch Mass: 130 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: All-aspect IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 23 kg

Ammo & Radar Info
Radar: Needs Radar Trailer | Either RSR 420 / ESR 360 / RSR 320 or ESR 220 (Need Info)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

2. G6-HVM

Missiles:
SAVH-3
Range: 12-15 km

Spoiler

Caliber: 180mm
Launch Mass: 123 kg
Max Speed: Mach 3.5 (1,200.5 m/s)
Guidance Type: LOSBR
Max Overload: 40 G
Guidance Time: 24s
Warhead: 22 kg

Ammo & Radar Info
Radar: EDR 110 | Planar Array PESA | IEEE- L NATO: D | - (25 km Radar)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

3. ZA-HVM (RU Forum)

Missiles:
SAVH-3
Range: 12-15 km

Spoiler

Caliber: 180mm
Launch Mass: 123 kg
Max Speed: Mach 3.5 (1,200.5 m/s)
Guidance Type: LOSBR
Max Overload: 40 G
Guidance Time: 24s
Warhead: 22 kg

Ammo & Radar Info
Radar: PESA Radar with Flat Antenna Grating | IEEE: NATO L: D - (25 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

4. Cactus Crotale + Second Forum Suggestion

5jtu88k7eiw81

Missiles:
SAVH-3
Range: 12-15 km

Spoiler

Caliber: 180mm
Launch Mass: 123 kg
Max Speed: Mach 3.5 (1,200.5 m/s)
Guidance Type: SACLOS
Max Overload: 40 G
Guidance Time: 24s
Warhead: 22 kg

R440
Range: 5.5 km

Spoiler

Caliber: 150mm
Launch Mass: 80 kg
Max Speed: Mach 2.3 (800 m/s)
Guidance Type: ACLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 15 kg

Ammo & Radar Info
Radar: Thomson-CSF J-band monopulse radar - (16 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

Japan:

Spoiler

1. Type 11 Tan-SAM Kai II

Missiles:
Type 11
Range: 15 km

Spoiler

Caliber: 160mm
Launch Mass: 103 kg
Max Speed: n/a
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: Optical Tracking possible without Radar vehicle, Just like current Type 81 mod.(C).
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

2. MMPM / Chu-MPM + New Forum MMPM - Dual-Purpose Missile

MMPM

Missiles:
ATM-6
Range: 10+ km

Spoiler

Caliber: 140mm
Launch Mass: 26 kg
Max Speed: n/a
Guidance Type: SALH / FnF - LOAL
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: See Guidance Type
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - Single

3. Type 03 Chu-SAM + Additional Source #1 + Additional Source #2 - Patriot Style System

Missiles:
Chu-SAM
Range: 50 km

Spoiler

Caliber: 320mm (Estimated)
Launch Mass: 570 kg
Max Speed: Mach 2.5 (857.5 m/s)
Guidance Type: Active AESA Radar Homing
Max Overload: n/a
Guidance Time: n/a
Warhead: 73 kg

Ammo & Radar Info
Radar: Active phased array antenna | Needs Radar vehicle
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - Single

4. AWX (1978 / 1983)

Guns:
35mm Oerlikon KDA
Range: ~~

Spoiler

Rate of Fire: 550 rpm
Ammo Types: API-T / HEI-T / APDS / AHEAD

Ammo & Radar Info
Radar: Inherits Type 87 Radar
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

5. CCV

pgwb50y50d491

Guns:
40mm CTA
Range: ~~

Spoiler

Rate of Fire: 750 rpm
Magazine Size: 100 rounds
Ammo: 400 rounds
Gun Angles: -10° to +45°

Ammo & Radar Info
Radar: Unknown
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

China:
Taiwan - Pakistan

Spoiler

1. HQ-6 / LY-60 + Additional Source #1 – Patriot Style System

Missiles:
HQ-6D SAM
Range: 18 km

Spoiler

Caliber: 203mm
Launch Mass: 220 kg
Max Speed: Mach 3 (1,029 m/s)
Guidance Type: SARH / ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 33 kg

Ammo & Radar Info
Radar: Radar Vehicles Needed
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

2. HQ-17 | HQ-17A | HQ-17AE + Additional Source #1 + Additional Source #2

Missiles:
HQ-17
Range: 15 km

Spoiler

Caliber: 230mm
Launch Mass: 165 kg
Max Speed: Mach 3 (1,029 m/s)
Guidance Type: SARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 15 kg

Ammo & Radar Info
Radar: PESA E/F Band Search Radar and AESA G/H Band Guidance Radar - (25 km Search | 15km Tracking)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

3. ZRAK HQ-11 / HJ-11

hq-11-4

Missiles:
HQ-11
Range: 25-30 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: Phased-Array Radar (?? km)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

4. Yi Tian WMZ-551

Yi-Tian-WZ551-PDSAM-1S

Missiles:
TY-90 (In-Game)
Range: 6 km

Spoiler

Caliber: 90mm
Launch Mass: 24 kg
Max Speed: Mach 2.2 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: 12s
Explosive Mass: 1.5 kg

Ammo & Radar Info
Radar: Planar Array LPI Radar (18 km Radar | 10 km Tracking)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

5. WZ-551D

WZ551D

Missiles:
PL-9C
Range: 22 km

Spoiler

Caliber: 157mm
Launch Mass: 115 kg
Max Speed: Mach 3.5 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 40 G
Guidance Time: n/a
Explosive Mass: 11.8 kg

Ammo & Radar Info
Radar: Search Radar Radius - (20 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

5. Hunter-1 SAM

Chinese-Avenger-1S

Missiles:
TY-90 (In-Game)
Range: 6 km

Spoiler

Caliber: 90mm
Launch Mass: 24 kg
Max Speed: Mach 2.2 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: 12s
Explosive Mass: 1.5 kg

Ammo & Radar Info
Radar: Electro-Opitcal FCS | Infrared, Laser, thermal and TV Sensor (?? km)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

6. Yitian ll

Missiles:
TY-20R
Range: 20 km

Spoiler

Caliber: 160/180mm
Launch Mass: 150 kg
Max Speed: n/a
Guidance Type: ARH
Max Overload: 20 G
Guidance Time: n/a
Explosive Mass: n/a

TY-20I
Range: 20 km

Spoiler

Caliber: 160/180mm
Launch Mass: 146 kg
Max Speed: n/a
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: n/a
Explosive Mass: n/a

Ammo & Radar Info
Radar: Unknown Radar Specs
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

6. FK-1000

FK1000

Missiles:
KS-1000 (Similar to 2K22)
Range: 22 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: RF
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
2x 23mm
Range: ~~

Ammo & Radar Info
Radar: Phases Array Guidance Radar/ Tracking radar with K-Band
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

7. FK-2000

Missiles:
Unknown Missile Name
Range: 25 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
2x Rotary 30mm
Range: ~~

Spoiler

Rate of Fire: 8,000-10,000 rpm

Ammo & Radar Info
Radar: Unknown Radar Specs
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

8. ZRPK FK-3000 + Additional Source #1 + Additional Source #2

raketno-pushechnyi-fk-3000-iz-knr-optimizirovan-na-borbu-s-dronami-n03s7rte-1668131101.t

Missiles:
FK/3000L
Range: 10 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Unknown Missile Name
Range: 25 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: n/a
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
30mm
Range: ~~

Ammo & Radar Info
Radar: 4 Phased Array Radar - (30 km)
Ready Ammo - 6x Large Missiles | 48x FK/3000L
Stowed Ammo - n/a
Missile Config - Single

9. Type 625E

Missiles:
FB-10A
Range: 17 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

TY-90 (In-Game)
Range: 6 km

Spoiler

Caliber: 90mm
Launch Mass: 24 kg
Max Speed: Mach 2.2 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: 12s
Explosive Mass: 1.5 kg

Guns:
30mm
Range: 2 km

Ammo & Radar Info
Radar: Need more Research
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

10. SA2 76mm + Additional Source #1

SA2 76

Guns:
PJ-26 Type 76mm
Range: 10 km

Spoiler

Rate of Fire: 120 rpm
Ammo Types: HE-VT / HE
Gun Angles: -10° to +75°

Ammo & Radar Info
Radar: Electro-Optical surveillance and tracking panoramic sight
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

11. JRVG-1

DrJoD4cXcAAOXdR

Guns:
PJ-26 Type 76mm
Range: 10 km

Spoiler

Rate of Fire: 120 rpm
Ammo Types: HE-VT / HE
Gun Angles: -10° to +75°

Ammo & Radar Info
Radar: Search & Track - (20 km & 15 km)
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

12. FLV-1 SAM

FLV-1-SAM-System-1S

Missiles:
9M31 Strela-1
Range: 4.2 km

Spoiler

Caliber: 120mm
Launch Mass: 30 kg
Max Speed: Mach 1.8 (617.4 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 3 kg

Ammo & Radar Info
Radar: NRIET AS-901 | L-Band MTI - (20 km)
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

13. LD-35

Missiles:
TY-90 (In-Game)
Range: 6 km

Spoiler

Caliber: 90mm
Launch Mass: 24 kg
Max Speed: Mach 2.2 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: 12s
Explosive Mass: 1.5 kg

Guns:
35mm Revolver Cannon
Range: 10 km

Spoiler

Rate of Fire: 1000 rpm
Ammo: 400 rounds
Velocity: 1,050-1,175 m/s
Ammo Types: Able to fire any Geopard ammo
Gun Angles: -2° to +70°

Ammo & Radar Info
Radar: Shared with PGL-12 | E/O Unit | - (24 km Search | 12 km E/O Track)
Ready Ammo - 2x
Stowed Ammo - 4x
Missile Config - Single

14. LD-2000 (LuDun 2000) + Additional Source #1

ld-2000a_141

Missiles:
TY-90 (In-Game)
Range: 6 km

Spoiler

Caliber: 90mm
Launch Mass: 24 kg
Max Speed: Mach 2.2 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 20 G
Guidance Time: 12s
Explosive Mass: 1.5 kg

PL-9
Range: 15 km

Spoiler

Caliber: 157mm
Launch Mass: 115 kg
Max Speed: Mach 3.5 (754.6 m/s)
Guidance Type: All-aspect IR
Max Overload: 35 G
Guidance Time: n/a
Explosive Mass: 11.8 kg

HQ-10
Range: 9 km

Spoiler

Caliber: 127mm
Launch Mass: 20 kg
Max Speed: Mach 2 (686 m/s)
Guidance Type: IIR
Max Overload: n/a
Guidance Time: n/a
Warhead: 3 kg

Guns:
Type 730B 30mm
Range: 2.5 km

Ammo & Radar Info
Radar: C-Band Search | Ku-Band Track | TV/IR Track | Type 347G Radar - (12 km Search | 9 km Tracking)
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - Single

15. LY-70 CV + Additional Source #1

5c4a92acd397495bb4b0238b24faad35

Missiles:
LY-70R
Range: 6 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: ARH
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

LY-70IR
Range: 15 km

Spoiler

Caliber: n/a
Launch Mass: n/a
Max Speed: n/a
Guidance Type: IIR
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
Type 730B 30mm
Range: 2.5 km

Ammo & Radar Info
Radar: AESA Search | E/O - (90 km)
Ready Ammo - 6x and 8x
Stowed Ammo - n/a
Missile Config - Single

16. Sky Dragon 12

downloadfile-2

Missiles:
Tianlong 12/ SD-12/ FK-1000 (9M311)
Range: 12 km

Spoiler

Caliber: 76mm (Booster 170mm)
Launch Mass: 40 kg
Max Speed: Mach 2.62 (900 m/s)
Guidance Type: SACLOS
Max Overload: n/a
Guidance Time: n/a
Warhead: 9 kg

Ammo & Radar Info
Radar: Ku-band tracking-guidance radar | E/O Tracker - (15 km Radar | 12 km E/O)
Ready Ammo - 12x
Stowed Ammo - n/a
Missile Config - Single

17. Type 88 / PGZ-88 (Old Forum)

Type_88AAGUN_28A_290b05

Guns:
2x Type 76 37mm
Range: 9.4 km

Spoiler

Rate of Fire: 360 - 380 rpm
Ammo: 1000 Rounds
Ready Ammo: 250 Rounds
Elevation: -10 to +87
Muzzle Velocity: 1,000 m/s

Ammo & Radar Info
Radar: Type JM832 fire control system - (15 km)
Ready Ammo - n/a
Stowed Ammo - n/a
Missile Config - n/a

18. HRB-131/HN5C

F6D18008B22BA10869DF942A20C38C47

Missiles:
HN-5
Range: 4.4 km

Spoiler

Caliber: 72 mm
Launch Mass: 10.2 kg
Max Speed: Mach 1.45 (500 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 0.5 kg

HN-5C
Range: 7 km

Spoiler

Caliber: 72 mm
Launch Mass: 10.2 kg
Max Speed: Mach 1.45 (500 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: 0.5 kg

Ammo & Radar Info
Radar: Need More Info
Ready Ammo - 8x
Stowed Ammo - n/a
Missile Config - Single

19. ZBL-09 SPAAG

ZBL-09_30mm_SPAAG

Missiles:
FN-6
Range: 6 km

Spoiler

Caliber: 72 mm
Launch Mass: 10.77 kg
Max Speed: Mach 1.75 (600 m/s)
Guidance Type: IR
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Guns:
30mm Gatling Gun
Range: ~~

Ammo & Radar Info
Radar: Missile Dependent
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

Taiwan / RoC -

1. Antelope -

Antelope

Missiles:
TC-1L Sky Sword SAM
Range: 9 km

Spoiler

Caliber: n/a
Launch Mass: 90 kg
Max Speed: Mach 2.5 (857.5 m/s)
Guidance Type: Dual-Spectral IR / FnF
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: CS/MPQ-78 (Track/Search RADAR) | Pulse Doppler | - (30 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

2. TC-2 + Additional Source #1 + Additional Source #2 – Unknown Patriot Style System

TC2

Missiles:
TC-2 - Sky Sword II
Range: 15 km

Spoiler

Caliber: 190 mm
Launch Mass: 184 kg
Max Speed: Mach 6? (2058 m/s)
Guidance Type: DL | ARH | ECCM
Max Overload: n/a
Guidance Time: n/a
Warhead: 22 kg

Ammo & Radar Info
Radar: Need more Info
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

Pakistan -

1. LY-80 / HQ-16A + Additional Source #1 – Patriot Style System

nq-16a

Missiles:
HQ-16A LY-80
Range: 40 km

Spoiler

Caliber: 340 mm
Launch Mass: 615 kg
Max Speed: Mach 3.49 (1200 m/s)
Guidance Type: SARH
Max Overload: n/a
Guidance Time: n/a
Warhead: 70 kg

Ammo & Radar Info
Radar: Radar Vehicle Needed - S-Band 3D Passive Phased-Array Radar - (140 km)
Ready Ammo - 6x
Stowed Ammo - n/a
Missile Config - Single

2. FM-90 / HQ-7B + Additional Source #1

Pakistan_unveils_new_Air_Defense_sytem_FM-90_HQ-7B_manufacturing_by_China_640_001

Missiles:
HQ-7B
Range: 15 km

Spoiler

Caliber: 156 mm
Launch Mass: 85 kg
Max Speed: Mach 2.3 (750 m/s)
Guidance Type: SARH | E/O | IR
Max Overload: n/a
Guidance Time: n/a
Warhead: n/a

Ammo & Radar Info
Radar: S-Band AESA Radar - (25 km)
Ready Ammo - 4x
Stowed Ammo - n/a
Missile Config - Single

Part 2

Italy - France - Sweden - Israel - Misc

YaSen · July 25, 2024, 7:06am

Iirc they had only OSA-AK variant (9K33M2)

Spain isn’t a subnation for Italy, but Hungary is, plus it’s been said by Smin that Romania is also a part of the Italian TT, so it can get Hungarian Unimog with Mistrals and Romanian OSA-AKM and Gepard with CA-94M.

Spoiler

Such systems us Spada 2000, MIRADOR-ELDORADO-INDIGO from Italy and Soviet Kub from Hungary/Romania (maybe also some Soviet older systems) can be mentioned.

lxtav · July 25, 2024, 7:35am

+1, on the topic of british SPAA, a few more could be added;

First is the supacat (ASRAAM) put together for Ukraine that uses a Supacat HMT chassis to fire at least 2 ASRAAM

image1079×666 75.5 KB

Next is the Stormer AD, which is an SPAA system mounting stingers and either a 25 or 30mm cannon, depending on what BR you consider “High” this might be too low however

image1310×855 94.7 KB

There is the rapier laserfire, which seems to be a rapier system mounted on a different hull and with only 4 missiles

image1251×1073 80.9 KB

Theres the Warrior Verdi 2, which is a Warrior IFV armed with starstreaks and a 40mm cannon

image1280×661 123 KB

And finally there is the warrior ADATS, this is a finicky one because its debated on whether it was real or a mockup, but for the most part seems real

image1200×685 79.9 KB

There are also quite a few more that im not sure if they meet the criteria that ill add in the spoiler below

Spoiler

Shorland S.53 Armed with Starburst (improved javelin) missiles

Land rover starburst

There are also a wide array of jeeps and trucks similar to the above mounted with Javelins and Blowpipe

There is also the cursed south african SPAA, the ZA-HVM, which was actually real, although you would have to get the details from @DevilO6

DevilO6 · July 25, 2024, 7:38am

I have been summoned
If you want to know things about ZA-HVM you can look here

If everything goes well a suggestion for G6-HVM made by me will be up soon too.

Armen_Lozone · July 25, 2024, 7:42am

defo must get accepted. they cant deny this one

Tactical_ra1nbow · July 25, 2024, 7:46am

HISAR, ADAMS, Rapier, OSA and Verdi2 are OK.
Others won’t be in the game, because they require additional radar and command vehicles

DevilO6 · July 25, 2024, 7:52am

Oh they sure can. I think i got enough proof that they should not, but in the end they can.

Armen_Lozone · July 25, 2024, 7:53am

hopium++

Tactical_ra1nbow · July 25, 2024, 8:06am

It’s not real. Cardboard turret on the real roikat. Actual missile launch was only from a ground-based test unit.

DevilO6 · July 25, 2024, 8:10am

It was real. I found a few sources confirming that, and i have a verbal confirmation from SA AA veteran. All that is left is finding a picture.

DevilO6 · July 25, 2024, 8:12am

Also

Tactical_ra1nbow · July 25, 2024, 8:29am

All systems worked separately (it is not known how well or if they worked at all), nothing was installed on the Roikat itself.

I’ve seen your post

You can see the variant on the Crotale chassis. Snail has already done so to sidam 25 and painted Mistral missiles for him, of which there were only three

Hartsy1 · July 25, 2024, 11:13am

I’m surprised more of these ain’t already in game, some tree’s are lacking badly.

Arctic-Fox · July 25, 2024, 1:04pm

Why would the Norwegian NOMADS go to the USA?
Sweden and Germany makes sense but did the US have anything to do with it?

Sanchouzz · July 25, 2024, 1:23pm

Skyguard-M just rock!

Can be used by almost all nations, due to big list of available ordnance.
And also it’s “all in one” system, as USSR/Russian Tunguska/Pantsir.

PercussionCap · July 25, 2024, 1:33pm

This is the 1978 AWX for japan. This came before the Type 87, and it was concluded that the turret was too heavy for the Type 61 hull. Later they used the same setup on said Type 87.

Not sure if it fits your high tier theme, but hey I’ll stick it here anyway.

SpeclistMain1 · July 25, 2024, 2:06pm

One thing that could be added to Italy is a 127mm or 155mm artillery tank using the Vulcano guided munition.

Range - 55km (155mm on 155/39 cannon), 70km (155mm on 155/52 cannon), or 80km (127mm on 127/64 cannon)
Guidance - GPS or Semi Active Laser (SAL) for the 155mm, and GPS, IR, or SAL for the 127mm
It appears both rounds can be fired standalone using portable programming devices

The main issue is that while they are meant to hit moving naval targets (the 127mm is, at least), the effectiveness against aircraft isn’t talked about anywhere even though the SAL and IR guidance should allow for it.

Bossnage · July 25, 2024, 3:47pm

gaijin is gonna look at this list and end up only adding the pantsir s2

RemoveCASfromGRB · July 25, 2024, 4:35pm

Update #1

Added:

MIM-46 Mauler
Stormer AD (Blazer-25/30)
Warrior VERDI-2
Geopard (CA-94M)
Mistral Unimog

Kingtiez · July 25, 2024, 4:41pm

TOR-M2 should be added to the list and perhaps Pantsir-SM
