The Field and Workshop Mods of Vehicles, new builds and Prototypes

Here in this topic ill post the pictures that i encounter of unquie field stuff and other modifications, that i either dont know what it is and or dont really feel like would be worth suggesting, but still interesting to share.

Feel free to also post stuff, take a peek and/or give insight what what might be.

This is a constant WIP post.

Unknown:(Click to show each)


Renault Indian Model 340 Truck with Magazin Fed gun (possiby 20mm C/38 L/65)



Truck mit 2 cm Flak 38 L/65




Unknown Vehicle with 7,5 cm StuK 37 L/24







Known:(Click to show each)


Kübelwagen mit 2 cm Flak 38 L/65



Pz.Sfl.II Model 1 and 2 7,5 cm K. L/41



Grille Ausf.M mit 3 cm Mk 103 in Baumaffe

(It propably cant turn 360° as its a free traverse gun and the gunner has to move around the axis of the gun, but it stands right in front of the plate and opening.)


Morris CDSW with Mg 151 Drilling



Morris CDSW with 4,7 cm Pak 36/37 Böhler



Bergepanzer IV Ausf.D mit 5 cm Pak 38 L/60



Sd.Kfz.251 Ausf.C mit 2 cm KwK 38 L/65 unknown mounting type, comparing to the other most likely Sockellafette.



Sfl.Bren (e) mit 2 cm Flak 30 L/65



Pz.Sp.Wg. P.204(f) mit 7,92mm Mg 81 (could have 22mm S.m.K.H)



Panzer IV mit 2 cm Flakvierling 38 L/65



Sd.Kfz.251 Ausf.D with 2 cm Flak 30 L/65 in makeshift mounting



Sd.Kfz.251 Ausf.D mit 2 cm KwK 38 L/65 in Sockellafette.



2209_zpsf992f023
2206_zps8744114f


Sd.Kfz.251 with 2 cm C/30 L/64 in some free aiming mounting


German Produced Ford Truck with 20mm L70 M1938 (Oerlikon)



Henschel 33 B1 Truck with 2 cm C/30 or C/38 L/65



7,5 cm Fk 231 (f) L/36 on french DDB Car, would use german ammo.



Citroen Type 45 U with 7,5 cm Fk 231 (f) L/36



Horch 108 with 4,2 cm Pak 41



Citroën U23 Truck with 2x 8 or 10 cm Mortars.



Steyr 1500 / 2000 S / A with 12,7 mm Scotti Isotta HMG






Krupp-Daimler KD-I Gepanzert mit 5,7 cm Flak


Overall known, however i cant find any info on the Gun, most importantly the velocity, otherwise it would use the standart 5,7 cm Ammo produced by germany.

4 Likes

I found this pic but didn’t find what the vehicle is

Spoiler

Found the gun it’s a 20mm L70 M1938 (Oerlikon).
Truck unknown still looking for it.

Spoiler


7604015

Unable to tell what the truck is still looking

This is a Henschel 33 B1

Spoiler

Henschel_33_B1_(1928-1933)_of_the_Reichswehr

Still looking for the gun

Unable to tell still looking

This is some goofy French shenanigans

Spoiler

https://www.militaer-wissen.de/canon-de-75-antiaerien-mle-1913-1917/?lang=en
https://www.reddit.com/r/shittytechnicals/s/RcJqXZu2yL


img_50-1_51

3 Likes

I found the truck it’s more than likely to be an Opel plitz

Spoiler

images
LKW_Opel-Blitz (1)
59d56c27489e5_Opelflak2.jpg.fe884e41d1ae0c96753aa81851a8dc29
images (1)
Opel-Blitz-Flakvierling

Edit: after further looking it’s not an Opel the window and the door frame are biger than the Opel.

Then its most likely a German produced Ford Truck. The shape also looks fitting.

Picture:(Click to show)


I think you are wright the frame and the carriage looks very similar


I found some more pics, which ill post when im vack home.

It’s a Citroën U23

1 Like

Aparently thats a Renault Indian Model 340 Truck.

Not much time, so i just throw the pictures in, without names.







2nd bunch


1 Like

I completely forgot about this topic so let’s start.

The first on is Bedford OY the gun is Madsen 20 mm cannon or orlikon 20mm

2.and 3.Idk what i am looking for there

4.is 20mm Scotti anti-aircraft gun on a Sd.Kfz but now what type exactly.

5.same gun as 4.

6.and 7.DShk on a Ford Barn.

8.Dodge WC series can’t tell what the gun is.

9.Büssing-NAG Burglöwe can’t tell what the gun is.

10.That’s a Zis-6 37mm the truck might be an Opel plitz or Ford or even a Mercedes-Benz.

First is just Sd. Kfz. 10/4 with some kind of 20mm gun
2.and 3. Is just DShk

Thanks to @Spr4yz , it could allready have been closed in to be possibly a MAN-Saurer 1915 with Fahrpanzer 5 cm Gun.



1 Like

Germans despite over-engineering everything also are the equivalent of warhammer 40k Orks on pharmacy grade meth…
got a vehicle but no gun? strap a gun to it…
capture a enemy tank with a weak gun or broken gun? screw dragging around and deploying that trailer hauled anti-tank cannon, strap it to the top of the enemy tank and drive me to the enemy, it doesn’t matter that we cant read the the manual or gauges in a different language…
find a bigger gun than whats fixed to their vehicle? strap the bigger gun to it…

Krupp-Daimler Plattformwagen 1911 Gepanzert mit 5,7 cm Flak

Screenshot 2024-08-03 221743



Overall known, however i cant find any info on the Gun, most importantly the velocity, otherwise it would use the standart 5,7 cm Ammo produced by germany.

It could also be a 7,1 cm Flak L/30, tho on that gun i found nothing of. No data no info on ammo available.

After long search i came to the conclusion that the 5,7 cm is guesswork of some person for a book.
And 7,1 cm is 7,7 cm Missread and then copied over, because there simply are no written down proofs of a 5,7 cm Flak, pictures with the ammo show it too big and there is no information even from other sources (Notes on German Shells 1918) that a ,7,1 cm Caliber was ever encountered.

German Truck with 18 Lbs gun.

Here ammo of the 18 pdr gun, if interested:

German Truck with 7,7 cm FK 96 n.A.



1 Like

I love the Portée one! Even better is that in the last photo we see that it can also use an MG. It may be a small thing but it’s so helpful to be able to spray down bushes and fences to get better lines of sight or not lose speed when driving through where they stood.

On the 3rd picture, i dont think that its a 7,7 cm gun, because the barrle looks too thick and the band at the end of the barrle is missing, do you know what gun that could be?

7,62 cm Flak L/30 on Truck.

Daimler with 7,1 cm Bak (or 7,7 cm)
