Im not saying anything about their monetizing schemes. Im simply saying gaijins words doesnt really mean much. They always twist their words in the end and pretend theyve always said what theyre currently sayint

3 Likes

Amazing

4 Likes

7 Likes

Nice!, Good job

1 Like

Its been linked to my internal report which I made some 2 months ago haha.

5 Likes

Fingers crossed for March update. I can see a lot of these things being bundled together

1 Like

It is some version of BOL?

Spoiler


And is there any information about MAWS on Gripen?

It is the BOL739/2;

Spoiler

Okay, thank you for information

Btw, it is only for Jas-39E? Or A/C also can use them?

internal MAWS is 39E/F only

2 Likes

So, only BOH/ESTL for C/D, okay

Am i missing something from that, or does gripen do not have right and upwards mawsu?

they’re on the top side;


1 Like

Thanks

Gripen NG.

Spoiler

But on serial E’s I cant find this MAWSU

Spoiler


Maybe improved design

i don’t think there are any pictures of the serial gripen as there is only one at the moment.
but we have this video of the first serial E version:

Spoiler

https://www.youtube.com/watch?v=voq1zIt8BLA

where those sensors are present.

Edit:
Clarification, Swedish serial E, and most of the sensors on NG, not all.
the Brasilian E has been in service for about 2 years, but are also customized for Brazil, they don’t have exactly the same parts.

Got it, thanks for the clarification

i’m a bit sad to see this thread die so i’m going to bump it a bit with some information i don’t think i’ve seen here.
i was looking at ammunition for Swedish vehicles just to see if there were any discrepancies when i stumbled upon this:

Spoiler





https://web.archive.org/web/20210517043101/https://hemvarnet.se/UserFiles/Nyheter/utbildningsgrupper/livgardesgruppen/filer/AMKAT_DATABILD_2014.pdf

So the JAS39 seems to have 4 choices of internal BOP IR-flare sizes

  • 55mm at 0.66kg (660grams) and either one or two colors (visual colors or IR-wavelengths? unclear)
  • 1x1 inch at 0.11kg (110grams) and either one or two colors (visual colors or IR-wavelengths? unclear)

i’m unsure if the ones where the markings are “TP” instead of “JAS” can be used on JAS or not.
The 55mm seams to be multi flare packages as they are labeled “three bodies” (so 0.22kg each meaning 1x2 inch flares?).

Then only one choice for the external BOL IR-flares

  • IR-package 30grams

Then the chaff is divided into three packages for both internal (1x1 inch) BOP and external (perhaps 15kg/320 = 45grams?) BOL

  • Broadband
  • IJ band
  • X Band

further down in the document it shows the flares for helicopters and logistic planes.
