Backlog for the systems of the combat vehicle of the anti-aircraft missile and gun complex “Pantsir-SM-SV”
Left Column
- Башенная установка – Turret installation
- АКСС – Automated Control and Communication System
- Шасси ГМ 5970.05 – GM 5970.05 chassis
Top Row (above main vehicle)
- СОЦ с АФАР – Target acquisition radar with AESA
- ОЭС – Optical-electronic system (electro-optical sighting system)
- МРЛС ЦКБА – Multifunction radar station (developed by TsKBA)
- ЦВС – Central computer system
Right Column (top to bottom)
- ВОЛПД – Fiber-optic communication system (internal data links)
- АРМ – Automated workstations (operator consoles)
- Блоки СА – System blocks
- УВВ – Power distribution unit
- РП – Relay unit
- БВА – Computing and input/output unit
- БА – Power supply unit
Bottom Row (under vehicle)
- НС – Navigation system
- ВКУ – Computing and control module
Color-coded notes
- Green dashed outline – Newly developed
- Grey outline – Unified with the combat vehicle of the Pantsir-SM
3 Likes
