Engesa EE-17 Sucuri - the brazilian wheeled tank destroyer

Would you like this vehicle to be added?
  • Yes
  • No

0 voters

How would you like to see this vehicle available?
  • Tech Tree
  • GE /Premium/ Battlepass
  • No

0 voters

Where should it be?
  • France Tech-Tree
  • Latin american Tech-Tree
  • Italian Tech-Tree
  • i voted no

0 voters


Designation:

The name “EE-17 Sucuri I” and “EE-18 Sucuri II” (its sucessor) are unnoficial, since both the official Engesa brochures and proper technical documentation only calls the vehicles EE-17 Sucuri and EE-18 Sucuri.

Spoiler

The vehicle’s history:

At the end of the 70s, with the success of the EE-9 Cascavel and EE-11 Urutu, Engesa decided to invest in a new vehicle with the concept of a tank destroyer, a vehicle that will provide both high mobility and a powerful armament, being designed specifically to engage and destroy enemy tanks in the battle, with those characteristics in mind the EE-17 Sucuri was born.

Spoiler


Basic characteristics:

The EE-17 Sucuri is a 6x6 Tank Destroyer with a crew of four (driver, gunner, radio operator and commander). The vehicle has a length of 6.35 meters, width of 2.6 meters and height of 2.8 meters (with the gun). The vehicle has a weight in running order of 17.7 tons and a weight (combat weight) of 18.5 tons. the vehicle also stores a total of 43 rounds (23 in the turret and 20 in the hull).

Spoiler


Turret:

The EE-17 Sucuri uses the reliable French oscillating turret FL-12, used in the AMX-13. With an crew of two men (gunner and commander), the turret gives to the vehicle the capacity to use the autoloader system, it also has acess to LRF (TCV29) and NVD. It stores 23 rounds, 12 ready to fire (in the autoloader magazine). The total elevation is 17°30’ (of -5 to 12°30). It is equipped with ten periscopes (1:1 magnification) around the hatches and a monocular telescope (6:1 magnification) for cannon direction. It also carried 4 smoke launchers, 2 on each side of the turret.

Spoiler


Firepower:

The EE-17 Sucuri uses the CN-105 model 57, an powerful low pressure gun that was designed to use HEAT rounds and it has firing rate (electric or mechanical) of eight shots per minute. In addition, it had a 7.62mm coaxial machine gun, with a firing rate (electric or mechanical) of 800 rounds per minute and a range of 600m.

Spoiler


Ammunition:

Spoiler

Armor:

Its chassis was similar to that used by other vehicles of the company, a monoblock made of welded bimetallic armored plates with thermal and acoustic insulation. It had a door on the left side and another at the rear, as well as a hatch for the driver (with three periscopes) and another for the radio operator. It also had a rear towing hook and four lifting supports.

Suspension:

The vehicle suspension was also derived from the EE-9 Cascavel and EE-11 Urutu models. It had semi-elliptical leaf springs, stabilizer bars, and the rear “boomerang” axle, with lateral blades and an option to lock the differential. The wheels had cast iron spoke hubs and stamped steel rims, fitted with 18-ply bulletproof military tires (size 14.00-20). Like trucks, it had pneumatic brakes, hydraulic steering and a 24V electrical system.

Spoiler


Engine:

The EE-17 Sucuri uses the Detroit Diesel 6V53T, V-six, 5212 cm³ total displacement, two-stroke, turbocharged, water-cooled, Maximum Gross Power (SAE) 300 HP to 2800 RPM. The engine allows the vehicle to reach a maximum speed of 110 km/h on roads and a autonomy of 600km.

Spoiler


Transmission:

The EE-17 Sucuri uses the Allison MT-640 with four speeds forward and one reverse.

Spoiler

General Dimensions and Performance:

Spoiler

EE-17 Sucuri Technical Sheet:

Spoiler

Crew: 4
Weight in combat order: 18,500kg
Curb weight: 17,700kg
Wheelbase: 3.9m
Gauge: 2.1m
Minimum height from the ground: 6.35m
Length: 6.35m
Width: 2.6m
Height (with armament): 2.8m
Entry angle: 58°
Departure Angle: 81°
Maximum vertical obstacle: 600mm
Maximum lateral inclination: 30%
Ramp Climb Ability: 65%
Autonomy: 600km
Minimum turning radius: 8.05m
Weapon: the French CN-105 model 57 cannon and a 7.62mm machine coaxial
2 smoke grenade launchers on each side of the turret
Maximum speed on the road: 110 km/h
Engine: Detroit Diesel 6V53T, V-six, 5212 cm³ total displacement, two-stroke, turbocharged, water-cooled, Maximum Gross Power (SAE) 300 HP to 2800 RPM

More pics:

Spoiler


Sources:

Spoiler

"Uma realidade. brasileira. Desenvolvimento de. blindados sobre. lagartas 1967-1978. Expedito Carlos Stephani Bastos.

ANDRADE, Roberto Pereira de; FERNANDES, José de Souza. Veículos Militares Brasileiros. São Paulo: Aquarius, 1983.

“EE-17 Sucuri destruidor de tanques” - Expedito Carlos

Blindados no Brasil: um longo e árduo aprendizado, Expedito Carlos

EE-17 Sucuri Official Brochure.

ecsbdefesa.com.br – Blindados no Brasil – Um longo e árduo aprendizado – Vol 2

Allison Transmission: CONTENTdm

Satory 79

5 Likes

It reminds me of one of the French tanks but with a Latin American style, I love it

2 Likes

this would be very cool

2 Likes

I’d say +1, but not for any of the given trees.
Perhaps adding a “other” option for that?

2 Likes

When South America comes, this has to as well! +1

3 Likes

+1

1 Like

A while ago this exotic ee-17 sucuri with a 90mm turret was discovered, if anyone knows anything just comment here
