Hello everyone, I would like to suggest this Canadian armoured car known as the Otter.


History:
The Otter’s existence started when GMC Canada got the blueprints for the Humber LRC Mark III which they began to adapt for Canada. The prototype was ready in early 1941 where it was accepted as “Car, Light Reconnaissance, Canadian GM Mark I”. The Otter managed to have British weapons supplied to it giving it a .303 Bern light machine gun in the dome-like turret and .55 Boy’s AT used by the co-driver seat. Compared to the Humber it was based on the Otter used the Chevrolet C15 of the Canadian Military Pattern(CMP) trucks as of base. Other changes include a stubby nose with a more capable engine, a sloped roof and what is described as a characteristic tail. Production of the Otter started in mid-1942 and had 1761 units delivered. Although out of those units, only about 1000 found their way inside operational units with the rest kept at home in Canada for training and other various duties. In service, the Otter was one of the main reconnaissance armoured cars of Canada in WW2. The Otter’s primary service for Canada was in Sicily, Italy, Normandy, and the Low Countries. Along with the resonance role the Otter was used as a convoy escort with its turreted .303 as an SPAA gun. During the war, the Otter also served with the British RAF who used it as an anti-air and often replaced the .303 and the turret with a 20mm Oerlikon with a field modification of the vehicle. Post-war surplus was sold to the Jordanian Army which ended up in the various Arab armies of the time and even Israel. It was also bought by the Dutch who also used it in their conflicts post-war. The Otter was also used by the Italians as but of the allied surplus that helped rebuild their army.

More photos

Can-Otter-DennisBerkin
gm_otters_bc_1948
Otter france 1944
Otter_Light_Reconnaissance_Cars_in_Athens_1944_IWM_CNA_4660
otter_MkI_haugh3
specs2

Specs:

Year 1942
Vehicle Type 4x4 Armoured Car
Origin & Designer Canadian/GMC & HBC
Numbers Produced 1.761 (100
Crew 3
Main Armament 1 x .55in Boys Anti-Tank Rifle (Bow)
Turret Traverse 360° (Manual)
Secondary Armament 1 x .303 Bren Light Machine Gun (Turret)
Smoke Discharger 4in Smoke Mortar
Height 2.44m
Width 2.16m
Length 4.50m
Combat Weight 4.976 kg
Ground Clearance 0.20m
Fording Depth 0.61m
Climbing Ability 46°
Radio No 19 Set
Armour:
Hull Front: 12mm.
Hull Sides: 8mm.
Hull Rear: 10mm.
Hull Top: 12mm.
Hull Bottom: 8mm.
Turret Front: 8mm.
Turret Sides: 8mm.
Turret Rear: 8mm.
Turret Top: Open.
Engine GMC 6 Cylinder (Petrol)
Transmission 4 Forward & 1 Reverse
Maximum Road Range 161 km
Maximum Road Speed 75 kph
Sources

CANADIAN OTTER ARMOURED CAR Mk. I - Quartermaster Section
Canadian Otter armoured car
WarWheels.Net-  Otter Mk 1/2 Light Recon Car Index
Otter Light Reconnaissance Car - Wikipedia
Battlefront - Producers of fine metal and resin miniatures

2 Likes

Hmmm with an anti tank rifle that only pens 23mm of armor, not sure if it gonna fit the 1.0 br (maybe if they add ww1 tanks)?
