Japanese Consolidated PBY-6A

Would you like to see this in-game?
  • Yes
  • No
0 voters

His-Mil-PBY6A-5382Konan
Japanese Consolidated PBY-6A
The Japanese JMSDF (Japan Maritime Self-Defense Force) in the years 1956-1960 had two Consolidated PBY-6A flying boats in service. One of the planes with the number 5882 crashed on June 6, 1960 while landing at Osaka International Airport.
History
On July 1, 1954, the JMSDF (Japan Maritime Self-Defense Force) was formed, which, like other parts of the JSDF (Japan Self-Defense Force), had almost no equipment. Everything was in short supply, and the threat from the USSR and China was enormous. Therefore, based on the U.S.-Japan Mutual Defense Assistance Agreement, the Japanese received two Consolidated PBY-6A patrol aircraft as assistance from the U.S. The first PBY-6A arrived in Japan on February 1, 1956, and the second on May 20, 1956. These planes were sent to Kanoya Air Base in Kagoshima Prefecture. There, the aircraft were incorporated into the 2nd Kanoya Air Squadron, which was part of the Kanoya Air Corpsand from 1956 to 1957 served as patrol aircraft, which were quickly replaced by the Lockheed P2V-7 and Grumman S2F-1 aircraft. For this reason, the use of PBY-6A aircraft is changed.The aircraft were disarmed and redirected on 30 March 1957 to Omura Air Base, where they were incorporated into the 91st Squadron of the Omura Air Corps. From this point on, the Consolidated PBY-6A became training and rescue aircraft, and were supported by four Grumman JRF-5 aircraft. PBY-6A flying boats operated until 1960. On July 6, 1960, during landing at Osaka International Airport, a flap occurs, the PBY-6A aircraft with the number 5882 suffers damage to the fuselage and is withdrawn from service. Unfortunately, there is a large discrepancy of sources here, what happened to the second PBY-6A with the number 5881. Some sources claim that it was already withdrawn on December 23, 1959, others that it was not until November 1960.

Photo of Consolidated PBY-6A number 5881

His-Mil-PBY6A-5381Itami-Hirata
PBY-6A number 5881 , unknown year of photography ^
IMG_0003c
IMG_0003b
PBY-6A number 5881 ,1958 year ^

Photo of Consolidated PBY-6A number 5882

His-Mil-PBY6A-5382Konan
His-Mil-PBY6A-5382-195705-Ohmura (1)
His-Mil-PBY6A-5382-195705-Ohmura (2)
His-Mil-PBY6A-5382Konan (3)
PBY-6A number 5882 at Kanoya Air Corps , 1956-57 ^
His-Mil-PBY6A-01-19570330-Ohmura
PBY-6A number 5882 transferred to Omura Air Base ,March 30 1957 ^
His-Mil-PBY6A-01-19571001JieitaiKinenPejent
PBY-6A number 5882 ,October 2 1957 ^
His-Mil-PBY6A-5382W-196004Tsushima (2)
PBY-6A number 5882 , April 1960 ^
His-Mil-PBY6A-5382W-196005Itami-Takata (3)
His-Mil-PBY6A-5382W-196005Itami-Takata (4)
PBY-6A number 5882 during scrapping after an accident in June 1960

Construction description
The Consolidated PBY-6A is very similar to the Consolidated PBY-5A (Late) from the game, but there are differences between them, which I will present here.

  1. The stabilizer and rudder were raised (it is not known exactly by how much)
  2. Nose turret modified and rearmed with M2 machine guns
  3. The radar above the cockpit has received a new cover
  4. Improved the armor of the aircraft (it is not known how much)
Technical sketches

PBY-6A-Catalina4
Consolidated_PBY-6A_Catalina_BuAer_3_side_view

Armament, Armor, and Firing Zones

His-Mil-PBY6A-Gun
PBY-6A-Catalina3

General characteristics

  • Crew: 5-7
  • Length: 19,35 m
  • Wingspan: 31,7 m
  • Height: 6,86 m
  • Wing area: 130,06 m2
  • Empty weight: 9743 kg
  • Take-off Weight: 12383 kg
  • Maximum Take-off Weight: 16510 kg
  • Powerplant: 2 x Pratt & Whitney R-1830-92 Twin Wasp 14-cylinder air-cooled radial piston engines, 1,200 hp (890 kW) each
  • Propellers: Three-bladed constant-speed propellers

Performance

  • Maximum speed: 286 km/h
  • Cruise Speed: 200km/h
  • Range: ?
  • Maximum Range: 3842 km
  • Service ceiling: 4298 m
  • Time to Climb to: 25.7 minutes to 3048 m
  • Climb Rate: 3,2 m/s

Armament

  1. Guns:
  • 2 x Browning M2 12.7mm mobile coupled machine guns in the nose shooter station (1200 rounds (1100 per gun) (?)
  • 1 x Colt-Browning 7.62 mm movable machine gun in the ventral shooter’s position (500 rounds)
  • 2 x Browning M2 12.7mm mobile machine guns in side nacelles (478 rounds per gun)
  1. Bombs:
  • 4 x 454 kg (1000 lb) bomb (under the wings)
  • 4 x 227 kg (500 lb) bomb (under the wings)
  • 12 x 45 kg (100 lb) bomb (under the wings)
  • 8 x 147 kg (325 lb) depth charges (under the wings)
  • 4 x 205 kg (450 lb) depth charges (under the wings)
  • 4 x 295 kg (650 lb) depth charges (under the wings)
  • 2 x torpedo MK.13-3
  1. Fuel dump tanks
  • 2 x 1135 l (300 gal) in additional tanks

Armour

  • Armor stronger than the PBY-5A
  • Self-sealing fuel tanks (part only)

Summary
The Consolidated PBY-6A is an interesting flying boat for Japan in War Thunder. This plane is quite well armed and can fly straight ahead (sorry H6K4, you can’t). Additionally, this aircraft represents a piece of JMSDF history, which would give Japan an interesting premium or event aircraft. I encourage you to discuss in the comments and to share your own knowledge on this subject.
Finally, I apologize for the linguistic and logical errors because unfortunately English is not my main language and I had to use google translator.

Internet sources

Consolidated PBY Catalina - Wikipedia
海上自衛隊の装備品一覧 - Wikipedia
JMSDF Squadron Histories Part 1 | J-HangarSpace: Information on Japanese Aviation
コンソリデーテッドPBY-6A
コンベアPBY-6Aカタリナ
大空への追想 (198): 桜と錨の気ままなブログ
Test Page | J-HangarSpace: Information on Japanese Aviation
Consolidated PBY-6A Catalina : Consolidated / Convair

Book sources

fun
Thank you for reading the suggestion, see you in the next one. Good luck pilots
gigachad

2 Likes

A +1 from me! Seems like almost everyone has a large Flying boat premium at Rank I, except for Japan

+1, however…

Do we have any photos showing this modified turret with M2 HMGs on the PBY-6A in actual service (both American and Japanese)?

From what I know, no PBY-6A was ever officially received or modified to have twin .50 cals in the nose. All I found confirms they came standard with twin .30 cal bow turrets and radar. Very few were built, and most had their nose turrets removed postwar.

Yeah, I’ve seen Wiki articles claiming the -6A got M2 HMGs in the nose turret. And yes, I’ve seen that aircraft spec sheet listing 4 x .50 cals (from the PBY-6A Airplane Characteristics & Performance, 1 Nov 1944 - see below).

PBY-6A Airplane Characteristics & Performance (1 November 1944)

But here’s the thing: We’ve got this newer PBY-6A Standard Aircraft Characteristics doc (1 Aug 1948) that replaced all previous specs. This one clearly states only .30 cal M1919s in the nose turret, which makes me think the 1944 sheet was wrong.

PBY-6A Standard Aircraft Characteristics (1 August 1948)

Above, those barrels are way too small and short to be M2 HMGs.

Below, images show the difference between AN/M2 .50 cals and AN/M2 .30 cals. Identifying them is tricky, but you can usually eyeball the barrel difference.

Sadly, I’ve tried digging for more PBY-6A service records, hoping to find any mention of field mods, but I came up empty. As far as I know, only the PBY-5A ever got experimental twin .50 cal turrets.

5 Likes

maybe the catalinas will get their cockpits if they add another one

1 Like

a nice japanese premium.

1 Like
