Douglas XTB2D-1 Skypirate

   Hello everybody. I’d like to suggest the Douglas XTB2D-1 Skypirate for US aviation in War Thunder. The XTB2D-1 was a prototype, gigantic torpedo bomber built and intended for service with the US Navy’s modern aircraft carriers. Two prototypes were completed and took flight tests; however, the TB2D project was considered unnecessary and later canceled after the surrender of the Japanese forces in the Pacific.


Key Characteristics

  • Contra-rotating naval torpedo bomber
  • Widest wingspan
  • 4 x wing-mounted .50-cal or 20-mm guns, 2 x .50-cal dorsal turret, and 1 x .50-cal ventral turret
  • A typical payload of 4 x Torpedoes, 4 x 2,000 lb bombs, or 2 x 4,000 lb bombs

History

In June 1942, the aftermath of the Battle of Midway showed the US Navy the need for an advanced torpedo bomber capable of carrying more weapons load and flying at long range. At the same time, the Navy began to expand the size of its aircraft carrier fleet, as it ordered Essex-class and Midway-class carriers.

Douglas designers had been working on a replacement for the TBD Devastator torpedo bomber since 1939. They approached the Navy officials with the designers’ proposal design with an initial twin-engine configuration to provide the necessary power for versatility, such as undertaking the torpedo bomber, reconnaissance, and level-bombing roles.

The twin-engine design was later dropped in favor of the single-engine design. In November 1942, the Navy contracted with Douglas Aircraft Corporation to develop and produce their new bomber. Impressed with the mockup aircraft in early 1943, the Navy signed a contract and ordered the construction of two flyable prototypes and a static testbed, so the project officially began in late October 1943. These prototypes were designated XTB2D-1 and under the name of Skypirate.

The XTB2D-1 was the colossal aircraft of its time built in the United States. It had a wingspan of 70 feet, with a total wing area of 605 square feet, larger than the Avenger’s 54-foot wingspan. Its huge tail was six feet taller than the Avenger’s. The empty weight was over 18,000 pounds, and the maximum was over 34,000 pounds. The aircraft’s wings could be folded for the aircraft carrier storage and had the arrestor gear for the recovery operations. The aircraft’s wings had slotted flaps, with the center segments serving as dive flaps and the outboard segments also acting as ailerons. The slotted flaps could be dropped to relieve stress at high speeds or when turning.

The XTB2D-1 was powered by a single Pratt & Whitney’s 3,000-horsepower Wasp Major XR-4360-8 with a supercharger. It was driven by an eight-bladed, contra-rotating propeller system as a favored alternative to the conventional twin-engine configuration. The aircraft had a unique exhaust system for the engine; the exhaust ports from cylinders in alternating rows were combined to reduce the effects of backpressure, forcing the exhaust gas pressure out and efficiently increasing fresh air intake in the cylinders.

A modern tricycle undercarriage was fitted to provide better visibility forward and allow the large blades the necessary clearance while also simplifying weapons loading. The bomb bay was featured in the original design; however, this was eliminated, so the torpedoes and bombs would have to be carried externally with low-mounted wings. Each wing could hold two hardpoints for carrying 2,100-lb torpedoes or two bombs.

The aircraft was planned to have a 2 x .50-cal dorsal turret and a 1 x .50-cal ventral turret and was prepared to have four wing-mounted 20-mm cannons or four wing-mounted .50-cal machine guns.

Earlier in March 1943, 23 pre-production aircraft were ordered by the Navy; however, the TB2D-1 project faced slow progress, as the construction of the USS Midway aircraft carrier was delayed. It was not until October 1943 that the efforts resumed to make substantial progress with the two XTB2D-1s and a static testbed in construction.

On February 18, 1945, the first Skypirate prototype was rolled out of El Segundo, California. This prototype lacked both offensive and defensive armament. It later first flew on May 8, 1945. The second prototype was completed and flew later in the summer of 1945. Although the flight trials proceeded on schedule, the testing faced significant challenges, as one of the prototypes ripped its flap segments away but successfully landed safely. Other problems with the propeller surfaced and caused all flight tests to be suspended until after the work. These problems delayed the project from going further into the production stage. Additional resources for the project were halted due to the disruptions from the war.

The project resumed in 1947 at a slow pace; however, the Navy had started to lose interest in this expensive piston-engined project as it was considered obsolete. The surrender of the Japanese forces in the Pacific and delays in the Midway-class aircraft carriers caused the Navy to seek something else to fill the XTB2D-1’s role in the dawn of the jet and turboprop engine. Ultimately, the 23 pre-production aircraft on order were canceled. The flight trials were suspended, and the two prototypes were eventually scrapped in 1948.


Specifications

Douglas XTB2D-1 Skypirate

General Characteristics

  • Crew: 3 (Pilot, Turret Gunners)
  • Length: 46 ft (14.02 m)
  • Height: 18 ft 6 in (5.64 m)
  • Span: 70 ft (21.34 meters)
  • Wing area: 605 sq ft (56.21 square meter)
  • Propeller Type: 8-bladed Hamilton-Standard Super Hydromatic propellers
  • Propeller Diameter: 14 ft 1 in (4.29 m)
  • Powerplant: 1 × Pratt & Whitney R-4360-8 Wasp Major 28-cylinder 4-row air-cooled radial piston engine
    → 3,000 hp (2,237 k/W)
  • Internal Fuel: 501 US gal. (1,896.5 L)
  • Oil Tankage: 60 US gal. (227.1 L)
  • Empty Weight: 18,405 lb (8,348 kg)
  • Gross Weight: 28,545 lb (12,948 kg)

Engine Ratings

  • Takeoff:

    → 3,000 BHP @ 2,700 RPM @ sea level

  • Military:

    → 3,000 BHP @ 2,700 RPM @ sea level - 1,500 ft
    → 2,400 BHP @ 2,700 RPM @ 13,500 ft

  • Normal:

    → 2,500 BHP @ 2,550 RPM @ sea level - 5,000 ft
    → 2,200 BHP @ 2,550 RPM @ 14,500 ft

Performance with Two Torpedoes

  • Power-to-Weight Ratio: 0.11 hp/lb (0.17 kW/kg)
  • Sea Level Speed: 254 mph (408 km/h)
  • Critical Altitude Speed: 271 mph @ 15,300 ft (436 km/h @ 4,663 m)
  • Stall Speed Gross Weight: 74.8 mph (120 km/h)
  • Stall Speed Without Fuel: 70.6 mph (114 km/h)
  • Wing loading: 47.1 lb/sq ft (229.96 sq m)
  • Take-off Distance - Calm: 1,019 ft (311 m)
  • Rate of Climb at seal level: 1,390 fpm (7 m/s)
  • Time to Altitude:
    • 8.2 minutes to 10,000 ft (3,048 m)
    • 22.3 minutes to 20,000 ft (6,096 m)
  • Service Ceiling: 25,500 ft (7,772 m)
  • Max. Range: 1,085 miles @ 141 mph (1,746 km @ 227 km/h)

Armament

  • Guns:
    • 4 x 0.50-cal. M2 Browning wing machine guns (400 rpg; 1,600 rounds)
    • 2 x 0.50-cal. M2 Browning machine guns in dorsal turret (400 rpg; 800 rounds)
    • 1 x 0.50-cal. M2 Browning machine gun in ventral turret (400 rounds)
  • Bombs:
    • 2 x 4,000-lb bombs
    • 4 x 2,000-lb bombs
    • 4 x 1,000-lb bombs
    • 4 x 500-lb bombs
  • Depth Bombs:
    • 4 x 650-lb depth bombs
    • 4 x 325-lb depth bombs
  • Naval Mines:
    • 2 x Mk 12-1 mines
    • 1 x Mk 13 mine
  • Torpedoes:
    • 4 x Mk 13-2 Torpedoes
  • Drop Tanks:
    • 2 x 300-gal drop tanks

Supplemental Data


Diagrams


Images



Conclusion | Why it should be in the game

   The Douglas XTB2D-1 Skypirate was a late-war American naval bomber intended for use in the Pacific Theater with the US Navy. It was built to be a gigantic aircraft with a contra-rotating engine designed for air-to-sea combat with heavier payloads, with four torpedoes in one go. I would like to see this aircraft coming with four wing-mounted cannons and defensive turrets, and it would be a fun squadron or event-premium vehicle for War Thunder. This aircraft and its lethal payload may be more valuable to use in naval sea battles.


Sources


Thank you for taking the time to read my suggestion! 😃

10 Likes

hell yeah! 'merica!

2 Likes

Naval needs this.

2 Likes

That is a WILD plane! Would love to play it! +1

1 Like

+++++++1111111

An absolute +1 from me! I’d love to see this thing pop up at some point, would be pretty neat

1 Like

Here’s an artist’s impression of what it’d look like with the turret installed and carrying the maximum torpedo load. IIRC, it could only carry this heavier load when taking off from a full runway on land.

2 Likes

It’s war thunder they will make it be able to take off from a carrier.
