Dassault Rafale - Variants, Characteristics, Armament and Performance

when is it all set to enter service? all of this seems pretty far down the line

F4.2 next year (2025)

F5 ? Difficult to say for now, but around 2030

2 Likes

Maybe 8% but that is approximately the lowest you’ll find for channel losses on a fighter jet capable of mach 2. The reason is that there is friction and pressure changes in the intake tunnel leading to the engine that will cause such losses.

The geometry of the intake must be long enough and shaped in a sufficient manner to produce shockwaves at supersonic speeds. These waves are shaped in a manner that they slow down the incoming air to subsonic speeds - optimally below 0.5 mach before they enter the engine. This also causes compression and makes it so that less compressor stages are required of the more modern turbofans.

With any design, the intake lip itself is optimized for certain flight envelope conditions and it is almost always not optimized for static operation. As such, channel losses at static conditions are at a lower limit of around 8% and an upper limit around 10% for modern fighter aircraft for all the above reasons.

Some accelerations been made and with luck some Rafale F5 could already be seen in service as soon as 2027-2028.

3 Likes

the F5 thingy i’m waiting for the most is FMAN/FMC (FC/ASW)

that thing looks stupid as hell (in a good way)

On the same assessment, we can consider HX Challenge,…

F-35 was called to be tested in finland by 4 cells
Only 2 of the 4 cells arrived, due to “tanker aircraft problems”

Alongside that 2x C-17 Glomaster III transport aircraft (150+ tons of capacity) came by for the logistics of the 2xF-35

And tests (40 flights) were completed by only 1 aircraft (out of 4 announced), due to complications for the second aircraft that arrived.

,…

In comparison, France sent 2 Rafales, and only 1 C-130 transport aircraft (19 tons of cargo, in C-130H standard)

PS:
Photo about TARGO II from Elbit, used on french F.3R standard aircrafts, within this source - photo are recent, those were made at HX Fighter Challenge in Finland January 2020
Source: https://omnirole-rafale.com/hx-challenge/)

Yep, silly little nose camera thingo definitely no longer tracks any air targets locked up with irst or radar. Definitely unhelpful for target ID. Was this an intended change if anyone knows?

1 Like

Are there any sources that can either affirm or challenge the current implementation of the Rafale’s in game FM? It seems like the Mirage 2000 shouldn’t be able to out-rate the Rafale at low speeds nor should the Rafale rip its wings in level flight, but I can’t find definitive sources that neatly compares the Rafale’s maneuverability with other fighters, flight manuals strictly warning pilots against flying with burners on at low altitudes, or anything of the like that would at least confirm or deny the legitimacy of how the plane is depicted in game right now.

5 Likes

Rafale should have reduced infrared signature
https://community.gaijin.net/issues/p/warthunder/i/PxnCSnRrUmnl

11 Likes

Love to see it, modern technology is amazing

https://community.gaijin.net/issues/p/warthunder/i/a2dRgFaJLTk2
what nonsense, Raphael doesn’t have a body shape to reduce RCS

Merry Christmas !

2 Likes

Responding to one questionable statement with another questionable statement is the wrong way to go.

What about the B-1B on your picture?

lmao what is this nosense?

Yeah so Rafale doesn’t have a shape to reduce RCS but B1B does. Interesting… Also all numbers on this bad made chart are false but whatever floats your boat mate. Rafale is a Low Observability aircraft, meaning it has a RCS between 1m² and 0.01m² without RAM coating a clean Rafale has a RCS of arround 1m² so going below 1m² isn’t reality bending.

7 Likes

Actually, this is not a dubious statement, but a picture from a book.

Rafale rcs .001 m^2

Pure uncoated Rafale cannot have 1m^2, and 0.001m2 is at a limited angle with a certain frequency

Which doesn’t make it any less dubious.

1 Like
