Shaanxi Baojii Special Vehicles Lie Ying Falcon Gyrocopter - What

Would you like to see this in-game?
  • Yes
  • No (Explain why)
0 voters

Suggestion No.64

G’day lads. I want to suggest a…uh…I guess a medium tier helicopter (well, gyrocopter) for China, having, for some reason, quite advanced weapons and sights (considering whatever it is mounted on), which the Shaanxi Baojii Special Vehicles Lie Ying Falcon Gyrocopter has! (The long name doesn’t help it either))))

Description:

Spoiler

The Shaanxi Baojii Special Vehicles Lie Ying Falcon, also referred to as the Hunting Eagle Strike Gyrocopter, is an advanced autogyro developed by the Chinese company Shaanxi Baojii Special Vehicles Manufacturing. Designed primarily for police and military applications, it features a tandem two-seat configuration, an open cockpit, tricycle-style landing gear, and is powered by a Rotax 914 engine in a pusher arrangement. This aircraft integrates a two-bladed rotor system and can reach speeds of up to 180 kilometers per hour, with a payload capacity of 220 kilograms when fully fueled. Based on German autogyro technology, it offers versatility in operation, including a three-seat variant and the capability to carry armaments like anti-tank guided missiles. The Lie Ying Falcon gained significant attention during its appearance in the 2019 China National Day military parade and is popularly nicknamed the “air tricycle” due to its distinctive design.

b7525df3-9a86-4cc0-a4f8-490cdf34b744



History:

Spoiler

This things history begins in the early 2010s, when the Shaanxi Baojii Special Vehicles Manufacturing Company sought to expand beyond its expertise in armored ground vehicles into aerial technology. Drawing heavily on German autogyro designs, the company wanted to create a versatile and cost-effective aircraft that could address both reconnaissance and combat needs.

The prototype of the Lie Ying Falcon made its maiden flight in 2011, where its capability to provide agile and efficient support in various operational scenarios was shown. After its initial testing, it led to further development and refinement, and by 2015, the model had entered production. The aircraft was designed not only for surveillance and reconnaissance but also with the capability to carry weapon systems, such as anti-tank guided missiles, making it a dual-purpose platform for intelligence gathering and offensive missions. A triple seat variant, where it was seen carrying (I assume) 2 AR-2 ATGM’s in 2018.


The Falcon gained a lot of attention during the 2019 China National Day military parade, where a whole lot of them were shown, albeit unarmed.


Armaments:

Spoiler

4x AR-2 ATGM’s (can have 6 if the 2 front mounted ones are there), with a 8km range. Has a weight of 20kg and a warhead of 5kg.

2 different types of optics



Specifications:

Spoiler

The Falcon has a main rotor diameter of 8.4m, and therefore has a main rotor area of 55 square meters. It weights 290kg when empty, and has a MTOW of 560kg. There are 2 variants, one having two seats (pilot + gunner?) and one with 3 seats (pilot + gunner and another member?). Powering it is a Rotax 914 engine, generating up to 100hp. This makes it go up to 180km/h, with a cruise speed of 150km/h and has a rate of climb of 2.5m/s.


Sources:

Spoiler

Shaanxi Baojii Special Vehicles Lie Ying Falcon - Wikipedia

China Shows Off Gyrocopters Armed With Anti-Tank Missiles

INFORMATION

Shaanxi Baoji Hunting Eagle: Special Purpose Gyrocopter

PLA Air Force news, pics and videos | Page 87 | Sino Defence Forum - China Military Forum

Shaanxi Lie Ying / Falcon

Thanks a lot for reading! If you have any extra information, then feel free to share them in the replies! As always, have a good day :)

2 Likes

who needs stealth helis when you can just be a flying chair with missles and tires

4 Likes

Littlebird from temu

2 Likes
