Why not? We already had Copy Paste in BP too so they might make one Event, another BP and one Premium for 60€ or so would be my guess
Sweden seems to have build a Mock Up Prototype with an 140mm Gun and a secondary 40mm Autocannon
But wasn’t functional obviously. I wonder if we can still get it in the Game
Theres also a nice 3D Model
Italy, Japan and China didn’t made any Prototype not even Mock Up or an MBT with above 120/125mm Gun from what i can find. Only studied by China and Japan but never built
1 Like
this is so profoundly stupid, its the kind of stupid that would inevitably be extremely strong ingame but useless irl
As long as the armor viewer says “wood”
They arent russians, so never gona be add… just see the last event mig 25 and then t-73 XD just gaijin things
Whats stupid about the Design? Must have some functionality if thats what actual Tank Designers came up with and felt confident enough to at least make a mock-up Prototype of it.
And according to the Article Sweden seriously considered building and using this Tank as their MBT but ultimately didn’t due to the cost of it
expensive and overgunned. you dont need 40mm autocannon ontop of a 140mm cannon, you are ampering limiting survivability to add a niche capability.
Comrade, ze Swedish wood is almost as strong as Soviet Stalinium, it will be glorious
We shall call it Swood
no no, maybe Swoodium?
Alright so, I recently was able to find a technical report on the CATTB that was through a pdf that didn’t give me an ad every 5 pages that lasted 10-30 seconds (to hell with Scribd). I found some interesting information in this pdf, although I don’t understand some parts of it. I hope by posting them I find someone who can understand them.
ALL INFORMATION IS DECLASSIFIED!
Weight
These pages appear to be weight and stuff to do with inertia. Based on these pages of information, the hull of CATTB weighed about 78,000 lbs (39 tons), according to table 4. For the pages for CATTB turret (Tables 1, 2, and 3), it has 2 different gun options when talking about weight and Moment of Inertia ( Ix(lb-in^2). I assume Gun (1) is the 120mm version of XM291, and Gun (2) is 140mm version of XM291, based on the different weights. Now this leads me to a slight hiccup, which is what the side armor thickness value refers to. There appears to be 2 different values, I’m not sure if there are 2 armor packages I’m not aware of, but what the side armor actually is (in terms of placement on the turret) can be found in the “Dimensions” section on figure 3 and page 4. Regardless, the minimum armor value stated for the “side armor” of the CATTB turret, is 40”, or 1016mm (with 50” being 1270mm). At the bottom of table 1, it shows 2 different weight values for both armor packages, with (1) being the values provided by the Gun manufacturer, and (2) being the values calculated using EMS (unsure of what this stands for). If we use the manufacturers weight, the turret appears to be 49,415lbs (about 25 tons) at 40”, and 57,795lbs (about 29 tons) at 50”. Using EMS, this puts the weight of the turret at 52,700lbs (about 26 tons) at 40”, and 61,000lbs (about 31 tons) at 50”.
So the total weight (hull + turret) of CATTB would be estimated at:
40” armor: 64-65 tons
50” armor: 68-70 tons
Page 4 (found after typing most of this out) also states that the side armor (front area (turret cheeks)) is 40” or 50” thick. Page 4 also states that the top armor (turret roof) is around 4 inches thick (around 102mm) except over the gun (?) where it is 2 inches thick (51mm). Page 4 also states that the spall liners are 1 inch (25mm) thick. No specific materials is listed for any armor layouts (at least that I’m aware of). Spall liner locations are available (in the turret at least) in figure 3 of “DIMENSIONS”.
Dimensions
These pages have to do with dimensions of the turret (note: the turrets appear to be mounted with the 120mm gun, I don’t know what LW stands for, but there was a 120mm version of the XM291). Also note that spall liners are pointed out. Figures 1 and 2 appear to be mounted without the additional armor, with figure 1 showing that the base armor is around 1 inch thick almost all around. Figure 2 looks like it shows the dimensions of the base armor. Figure 3 seems to show the CATTB turret with its add on armor equipped, plus it also shows the turret basket and gearbox for I assume turret controls? Also shows gunner and commander positions, spall liner locations, and by the looks of it, CATTB armed with the 120mm, has about 20° elevation and 10° depression?
Out of fear of losing progress, and maybe reaching the limit of words, I will end it here and do another part if I find more. Please go through the document yourself and double check all my work.
A little summary as well.
Turret thickness-
Front: 1016-1270mm
Roof: 102mm all over except over gun, 51mm
Weight: 64-70 tons.
2 Likes
Here are more things regarding the CATTB. Found these in a PDF of the AMC 1990 TECHNOLOGY EXPO.
Things I found for CATTB.
And some extra cool things, the HFHTB is something I think I’m gonna look into more (25mm chain gun on top of an M109 is awesome sounding).
1 Like
I have now reached the part where finding information has gotten difficult. The sources I have been reading now are probably not primary sources, so I don’t think they can actually be used. I will still put them in here anyways, just in case.
Pretty much, from all these sources (plus some things I have read not from the sources), the CATTB was powered by a Cummins XAP-1000 engine. This engine was a 1682 cubic inch V12 diesel, and produced 1450hp. It was mated to an Allison transmission of some sort (said to be an 1100 series) with an alleged top speed of 43 mph and a reverse speed of about 24 mph. The CATTB utilized a bustle autoloader (the XM91), which had a fire rate of about 8-12 rpm (5-7.5 seconds per shot), and held 17 rounds in the autoloader and 22 in the hull. It is said that the XM291 had a muzzle energy about double that of the M256 120mm cannons found on the Abrams (every time I see muzzle energy listed, it’s always double of the M256, so around 18 MJ). I have read that the CATTB was equipped with both a soft kill APS (AN/VLQ-8A, found on the M1A1 HC), and a hard kill APS (Trophy). I have also read that CATTB was only fitted with a soft kill APS.
Next week, I plan on starting to call around at different places which has had the CATTB at some point, to see if I could get more information and maybe even pictures (or maybe even go see it and get pictures myself). I tried looking through budget reports and what not, usually they only ever referred to the gun (XM291) in the 120mm configuration. I am really struggling finding information on the hull, it’s full selection of tech, and information on the ammunition. Its APS selection, reload rate, and speeds, could also all use more official looking evidence. If anyone has anything, throw it out there.
